Kollmorgen CE10251
Product Brief: Factory-molded, shielded power and feedback cable with pre-terminated motor-side connector and drive-side flying leads or mating connector, designed for interconnection between Kollmorgen AKM servo motors and AKD / S300 / S700 servo drives. CE10251 denotes a specific length and pinout configuration from Kollmorgen’s cable ordering scheme (typically motor power + brake leads + feedback in one or separate assemblies per customer order code).
Detailed content
Cable Type: Power + Brake (optional per config) + Feedback — multi-conductor, color-coded per DESINA standard
Conductor Specification (Power): 4 × (AWG 16–AWG 20) depending on current rating (for motors ≤ 12 A / 20 A), brake pair AWG 22–AWG 20
Conductor Specification (Feedback): Twisted-pair shielded signal wires, AWG 24–AWG 26, individually foil-shielded + overall braid
Shielding: Tinned copper braid + AL-foil overall shield, drain wire terminated at drive-end connector shell
Jacket Material: PUR (Polyurethane) — oil-resistant, flame-retardant per UL 20276/ IEC 60332-1; halogen-free option on later revisions
Rated Voltage: ≤ 600 V AC/DC (power cores); ≤ 30 V signal (feedback cores)
Rated Current (Power): Matched to motor — up to 12 A continuous (CE-series for AKM ≤ frame 4–5) or 20 A (larger frame variants)
Bend Radius (Fixed): ≥ 5 × outer diameter
Bend Radius (Flex / Trailing Chain): ≥ 10 × outer diameter (for flex-rated versions)
Temperature Range (Operation): –25 °C to +80 °C (PUR jacket)
Connector Type (Motor End): Rotatable IP65 Intercontec / M23 circular connector (pin count per motor feedback type: 17-pin for SFD/EnDat, 12-pin for resolver, etc.)
Connector Type (Drive End): Flying leads with ferrules OR pre-installed Phoenix / Weidmüller terminal block plug / M12 per drive model
Length: Defined by last digits of full order code (commonly 3 m / 5 m / 7 m / 10 m for CE-prefixed parts)
Compliance: CE, UL recognized component, RoHS, DESINA color coding
Applicable Industries: Semiconductor packaging equipment, CNC machine tool axis, printing & converting lines, food & beverage packaging (with appropriate washdown-rated motor), robotic joint cabling
Installation Requirements: Route power and feedback cables separately from high-voltage AC mains or VFD power cables (min. 200 mm separation or use metal partitioned duct); bond shield to drive chassis ground terminal only at one end (drive side) unless dual-end grounding specified; avoid sharp bend radii; verify connector keyway alignment before mating.
Usage Notes: Do not exceed stated current / voltage per conductor; inspect O-ring seal on motor connector before mating to maintain IP65; for hybrid single-cable (SFD3 / Hiperface DSL) motors use specifically designated hybrid cable — CE10251 is a legacy dual-cable or standard power+separate feedback type, not a single-cable hybrid unless explicitly so marked on label.
