Design: MOD — Modular Connector System

Length: 15.0 Meters

Conductor Count: Multi-Core (Typically 12+ Conductors for Resolver/Encoder + Power)

Shielding: Double Shielded (Foil + Braid)

Outer Jacket Material: PUR (Polyurethane) — Oil and Abrasion Resistant

Operating Temperature: -20°C to +80°C

Bend Radius (Min.): 5× Cable Diameter (Static), 10× Cable Diameter (Dynamic)

Connector End A: M23 or M40 (Drive Side)

Connector End B: M23 (Motor Side)

Rated Voltage: 300 V

Key Features:

• Modular Design Allows Field Replacement of Connectors
• EtherCAT Compatible Signal Integrity
• High Flex Life (> 10 Million Cycles)
• Resistant to Coolants, Oils, and Cutting Fluids

Applicable Industries: All Kollmorgen Servo Motor Applications Requiring External Cable Routing

Installation Requirements: Route Away from High-Current Power Cables (Min. 100 mm Separation), Use Cable Chain for Moving Applications, Secure with Clamps at 500 mm Intervals
