Kollmorgen AKD-P01206-NCA

Product Overview

AKD-P01206-NCA is performance-grade single-axis servo drive from Kollmorgen AKD-P platform. Model breakdown: AKD-P = high-performance mains-powered variant; 012 = 12 Arms continuous three-phase output current rating; 06 = 115V single/230V single/three-phase universal mains input hardware base; suffix NCA = native EtherCAT CoE real-time Ethernet bus, SFD single-cable servo feedback interface, standard analog/digital I/O configuration without STO safety function.
WhatApp
WeChat

Detailed content

Technical & Performance Specifications

  • Mains AC Input Voltage: Single/Three Phase 115–230 VAC (±10%), 50/60Hz universal grid compatibility
  • Continuous Phase Output Current: 12 Arms RMS
  • Peak Overload Output Current: 36 Arms RMS, sustainable maximum 5 seconds (300% continuous overload capacity)
  • Rated Output Power: 3.0 kW at 230V three-phase input
  • Velocity Loop Maximum Bandwidth: 2800 Hz
  • PWM Switching Frequency: 16 kHz fixed modulation
  • Control Loop Refresh Rates: Current loop 31.25 μs, Velocity loop 62.5 μs, Position loop 125 μs
  • Standard Communication Interface (N suffix): EtherCAT CoE real-time industrial Ethernet, RS232 diagnostic configuration port
  • Feedback Compatibility (C suffix): SFD single-cable power+feedback integrated servo cable, incremental sine/cosine encoders, resolvers
  • Analog I/O Channels: 2 × ±10VDC differential analog input, 2 × ±10VDC analog output
  • Digital I/O Channels: 8 × 24VDC optical isolated sinking/sourcing input, 4 × isolated open-collector output
  • Dynamic Braking Hardware: Integrated medium-capacity internal dynamic braking resistor for low/medium inertia load regeneration energy absorption
  • Complete Protection Function Suite: Overcurrent instantaneous shutdown, DC bus overvoltage/undervoltage lockout, heatsink overtemperature cut-off, motor winding thermal fault interlock, feedback signal loss protection, output phase short circuit, earth leakage fault interlock
  • Cooling Architecture: Passive extruded aluminum chassis natural convection fanless cooling design
  • Protection Class: IP20, installation restricted to industrial control cabinet DIN rail mounting only
  • Net Unit Weight: 1.25 kg
  • Outer Physical Dimensions (W × H × D): 45 mm × 220 mm × 175 mm

Material Composition

  1. Unified Chassis & Heat Sink: Integrated extruded 6063-T6 black hard anodized aluminum alloy anti-corrosion frame
  2. Main Control PCB: High-density FR4 flame-retardant lead-free printed circuit board with gold-plated signal contact pins
  3. Power Stage Assembly: Three-phase IGBT power bridge thermally bonded to aluminum radiator via high thermal conductivity silicone adhesive
  4. Terminal Connectors: PA66 flame-retardant insulated copper spring-clamp quick-disconnect terminals
  5. Dynamic Brake Resistor: Ceramic encapsulated wire-wound high-power resistor assembly
  6. EMI Isolation Baffles: Cold-rolled steel metal shielding separating high-voltage power zone and low-signal communication/feedback zone

Structural Features

  1. Slim vertical unified chassis-radiator integrated structure eliminating separate radiator assembly components
  2. Front panel segmented independent terminal zones for mains power, motor power, EtherCAT bus, SFD single-cable feedback, analog/digital I/O with internal metal EMI shielding barriers
  3. Fanless passive cooling system with external integrated fin array for full heat dissipation without mechanical fan assembly
  4. Onboard non-volatile flash memory preloaded with full parameter library for all standard voltage AKM and Goldline servo motor series
  5. Dedicated SFD single-cable feedback header reduces wiring port count between drive and servo motor
  6. Spring-clamp quick-disconnect terminals enable fast field wiring without torque screwdriver calibration adjustment

Working Principle

Single/three-phase AC mains input passes built-in passive EMC filter then full-wave diode rectifier to generate stable DC bus voltage supplying three-phase IGBT power inverter stage. High-speed DSP motion controller processes real-time EtherCAT CoE synchronized motion commands, sampling SFD single-cable integrated rotor position feedback signals at 16kHz PWM cycle. High-bandwidth triple closed-loop PI-PDFF control algorithms dynamically adjust three-phase sinusoidal output current to eliminate motor position tracking deviation and velocity fluctuation. During load deceleration regenerative energy generated by servo motor is consumed by internal dynamic braking resistor to stabilize DC bus voltage fluctuation. Continuous multi-channel hardware fault monitoring circuit samples all critical electrical and thermal operating parameters, triggering instant power stage hardware interlock shutdown upon fault threshold violation to protect drive and matched servo motor hardware.

Function Features

  1. Pre-stored full motor parameter database for AKM and Goldline B/M series servo motors, supporting one-click automatic motor identification tuning
  2. 2800Hz maximum velocity loop bandwidth delivers fast dynamic acceleration/deceleration response for mid-speed precision positioning axes
  3. Native EtherCAT CoE real-time bus supports multi-axis synchronized electronic gearing and electronic cam motion trajectories with synchronization jitter <100 ns
  4. Dedicated SFD single-cable feedback interface reduces total wiring quantity between drive and servo motor by 50% compared to separate power and feedback cables
  5. Integrated internal dynamic braking resistor eliminates external brake resistor accessory requirement for low/medium inertia mechanical loads
  6. Built-in adaptive digital anti-resonance filter suppresses mechanical axis low-frequency oscillation and audible vibration noise
  7. RS232 multi-drop diagnostic port supports batch parameter backup, restore and firmware upgrade via official Kollmorgen WorkBench configuration software

Advantage Highlights

  1. Fanless passive cooling architecture eliminates mechanical fan wear, dust clogging and fan burnout failure maintenance points
  2. SFD single-cable feedback design halves wiring material cost and field assembly labor time for multi-axis automation systems
  3. Slim extruded aluminum chassis reduces cabinet horizontal space occupation by 35% compared to equivalent power S300 series servo drives
  4. Universal 115/230V single/three-phase mains input adapts to all global industrial low-voltage factory power grids without external isolation transformers
  5. CE, UL/cUL, RoHS, REACH global safety and environmental compliance certification for OEM mass production automation equipment
  6. Complete galvanic isolation between high-voltage power circuits and low-voltage signal/EtherCAT communication circuits minimizes industrial site electromagnetic noise interference

Applicable Industries

Mid-speed automated electronic component assembly equipment, desktop CNC engraving and cutting machinery, optical inspection precision positioning stages, light-duty packaging labeling and dispensing automation lines, laboratory precision fluid handling robotic axes, small robotic pick-and-place mechanisms

Installation Requirements

  1. Mandatory vertical DIN rail cabinet mounting orientation only; horizontal flat mounting reduces passive heat dissipation efficiency by 38% and leads to power module thermal degradation
  2. Minimum unobstructed airflow clearance: 60 mm vertical space above drive top edge, 40 mm clearance on left and right lateral chassis sides
  3. DIN rail mounting metal backplate must connect to facility star protective earth grid via minimum 4 mm² shielded copper protective earth conductor
  4. Motor power wiring specification: For cable length ≤15 m, use four-core 1.5 mm² fully shielded copper SFD single cable
  5. SFD single-cable maximum transmission distance limited to 60 meters
  6. EtherCAT bus communication wiring: Standard CAT5e shielded Ethernet cable, install 120Ω terminating resistor at both physical endpoints of bus network
  7. Cable separation regulation: High-voltage mains power cables and low-level signal/EtherCAT communication cables must route inside physically independent cable ducts; unavoidable cross routing must adopt strict 90-degree perpendicular crossing only

Operation & Maintenance Precautions

  1. Cabinet ambient operating temperature range strictly limited to 0°C ~ +40°C; ambient temperature exceeding 40°C requires linear 15% continuous output current derate per 10°C temperature rise
  2. Monthly maintenance task: Use clean compressed dry air to fully remove dust accumulated on chassis aluminum heat dissipation fin array to maintain unobstructed passive heat dissipation airflow
  3. Disconnect all mains AC supply and wait minimum 5 minutes for DC bus capacitor full discharge before disassembling any terminal wiring connectors
  4. Prohibit connecting servo motors with rated power exceeding 3.0 kW to this drive unit; permanent IGBT power module thermal burnout damage will occur
  5. All SFD single-cable and EtherCAT communication cable shielding layers must implement double-end grounding to eliminate signal noise distortion and position jitter
  6. Storage environment must maintain non-condensing relative humidity ≤85%; prohibit deployment within control enclosures containing heavy oil mist, conductive metal dust or acidic/alkaline corrosive vapor atmospheres
  7. All firmware upgrade and motor parameter tuning operations must exclusively execute via official Kollmorgen WorkBench configuration software; unapproved third-party configuration tools void factory product warranty coverage
