Technical Specifications
Brand: Eaton
Display: industrial touch screen
Memory: 16 MB SDRAM, 32 MB Flash in listed legacy configuration; some sources list higher embedded HMI configurations
Input voltage: 24 VDC
Front protection: IP65
Rear protection: IP20
Operating temperature: 0–60 °C
Communication: Ethernet, RS232/RS485, USB, DVI depending on configuration
Functional Features
Touchscreen operator interface
PLC communication
Recipe and alarm handling
Industrial visualization
Multi-port connectivity
Structural Features
Panel-mount housing
Tempered glass display
Steel/chassis construction
Sealed front face
Material Composition
Steel chassis
Tempered glass
Industrial plastic/metal enclosure
Sealed gasket
Application Scenarios
Machine control panels
Packaging lines
Factory automation
Process visualization
OEM equipment HMI
Installation Requirements
Panel cutout per drawing
Use regulated 24 VDC supply
Ensure rear enclosure ventilation
Ground panel correctly
Usage Notes
Avoid sharp object contact with screen
Clean with non-abrasive industrial cleaner
Do not expose rear electronics to washdown
Backup HMI project before replacement
