Processor: Equipped with a 1.8GHz Pentium – M microprocessor.
Memory: 64MB of battery – backed RAM for program storage, and 64MB of non – volatile user flash memory.
Scan Rate: The typical scan rate is 0.024 ms per 1000 boolean contacts/coils.
Communication Interfaces: Support RS – 232, RS – 485 serial ports and Ethernet interfaces. The Ethernet interface has a data rate of 10M or 100M, with a 10BaseT RJ45 physical interface, and can support up to 16 web server and FTP connections in total for web – based data monitoring.
Power Requirements: +5VDC at 6.8 amps nominal, +12VDC at 0.003 amps nominal, and -12VDC at 0.003 amps nominal.
Operating Temperature Range: 0°C to 60°C.
Programming Languages: Support programming languages such as ladder diagram, C, structured text, and function block diagram.
Standard Compliance: Comply with the VME64 standard (ANSI/VITA 1), which is convenient for communication with I/O modules.
High – speed Processing: With a 1.8GHz processing speed, it can efficiently process various data and control instructions, and quickly respond to and handle real – time tasks.
Redundancy Design: Have hot – standby redundancy (HSB) function, which can improve the reliability and stability of the system. When the main CPU fails, the standby CPU can take over the work in time.
Rich I/O Support: Support discrete I/O and analog I/O, and can be connected to a variety of field devices to process various input and output signals.
Convenient Communication: Multiple communication interfaces make it easy to connect with programmers, human – machine interface (HMI) devices and other equipment, and support Modbus RTU slave, SNP and other serial protocols, as well as Modbus/TCP protocol.
Easy to Use and Maintain: It has a simple and easy – to – understand user interface and operation buttons, and supports programming software such as Proficy Machine Edition or Logic Developer, which is convenient for users to set, control, and carry out secondary development. In addition, it can be upgraded through RS – 232 or RS – 485 serial ports.
Application Scenarios
Manufacturing Industry: It is used in the production line control of the manufacturing industry, such as the speed control of conveyor belts, the action control of robotic arms, and the monitoring of process parameters, to ensure the stable operation of the production line and the quality of products.
Power Industry: Applied to power generation, power transmission and distribution systems, for the control and monitoring of generators, transformers, circuit breakers and other equipment, to ensure the safe and stable operation of the power system.
Petrochemical Industry: Used in the control of oil refining, chemical reaction, gas transmission and other processes, such as monitoring the pressure, temperature, flow rate of pipelines and reactors, and realizing emergency shutdown and other safety protection functions.
Water Treatment Industry: In water treatment plants, it is used to control the operation of water pumps, valves, and filters, as well as the monitoring of water quality parameters, to ensure the normal operation of the water treatment process and the quality of treated water.
Paper – making Industry: Used in the paper – making process, for the control of pulp preparation, paper – making machinery operation, and the monitoring of key parameters such as humidity and tension, to improve paper – making efficiency and product quality.
