Technical Specifications:​ Input 220 V AC single-phase or three-phase; output 0.75 kW; rated output current 4.0 A; position/speed/torque control; position resolution up to 1,000,000 pulses/rev; pulse input up to 500 kHz; differential 2500-line encoder; RS485 Modbus RTU; response 1.0 kHz; operating temperature 0°C to +45°C; size about 120 × 80 × 35 mm; weight about 0.5 kg.

Functional Features:​ Electronic gearing 1–10000; jog operation; multiple homing modes; limit-switch inputs; alarm relay; auto-tuning.

Application Scenarios:​ Small CNC routers, textile machines, printing machines, packaging equipment and light automation.

Performance Parameters:​ 4.0 A output at 0.75 kW; high-resolution pulse tracking; 1 kHz speed-loop response.

Material And Structure:​ Compact metal enclosure; terminal blocks for power, motor, encoder and I/O; DIP switches; status LEDs.

Working Principle:​ Receives pulse/analog command references, executes current/velocity/position loops, drives the servo motor through PWM power stage and feeds encoder feedback back to the controller.

Installation Requirements:​ Mount on panel or DIN rail; keep away from high-frequency interference; use shielded encoder cable within the specified length; ground the drive chassis.

Usage Notes:​ Perform auto-tuning with the motor connected and unloaded. Do not exceed 4.0 A continuous. Provide separate 24 V encoder supply if required.
