Technical Specifications
Processor: High-performance Intel Pentium III processor
Memory: Up to 512MB of synchronous DRAM
Graphics Accelerator: 64-bit AGP SVGA video graphics accelerator with 4MB SGRAM memory
Clock/Calendar: Battery-backed
Interface: VMEbus 6U form factor with dual-ported RAM for VMEbus interaction
Communication Interfaces: Supports Ethernet, RS-232, RS-485, and other communication protocols
Physical Dimensions: 130mm x 90mm x 40mm
Weight: Approximately 0.5kg
Operating System Compatibility: Supports VxWorks, Linux, MS-DOS, Windows 95, and Windows NT
Power Requirements: Typically 220V AC (specific voltage ratings may vary)
Functional Characteristics
VMEbus Controller: Operates as a VMEbus controller, enabling interaction with other VMEbus modules through a PCI-to-VMEbus bridge and Endian conversion hardware.
PC/AT Compatibility: Executes standard PC/AT power-on self-test (POST) and boots into compatible operating systems.
Advanced Features: Includes general-purpose timers, programmable watchdog timers, bootable flash disk systems, and non-volatile SRAM, making it ideal for embedded applications.
Video Graphics: Offers high-resolution graphics support up to 1600x1200x56k colors.
Front Panel Features: Equipped with reset switches and a mini-speaker for user interaction and diagnostics.
Application Scenarios
Real-Time Control: Ideal for applications requiring precise and real-time control, such as manufacturing automation, process control, and robotics.
Data Acquisition and Analysis: Suitable for systems that need to acquire and analyze large amounts of data in real-time, including monitoring and diagnostic systems.
Motion Control: Can be used in applications involving precision motion control, such as CNC machines and automated assembly lines.
Human-Machine Interface (HMI): Provides a robust platform for developing user interfaces, allowing for seamless integration with industrial displays and input devices.
Remote Monitoring: Enables remote monitoring and control of industrial processes, enhancing operational efficiency and reducing downtime.
