Technical Specifications
Processor:
VMIVME-7807 is equipped with a Pentium M processor, available in configurations of 1.1GHz, 1.4GHz, or 1.8GHz, offering excellent computational power and processing speed.
Memory:
Supports DDR SDRAM memory with a maximum capacity of up to 1.5GB, allowing for the handling of large amounts of data and complex applications.
Features a 200-pin DDR SDRAM SODIMM slot and optional soldered-on board memory for flexible memory configurations.
Storage:
Provides a bootable CompactFlash storage option with a maximum capacity of 2GB, offering a reliable and flexible storage solution.
Network Connectivity:
Equipped with dual Gigabit Ethernet interfaces, ensuring high-speed and stable network connectivity, suitable for applications requiring fast data transfer and network communication.
Physical Dimensions and Weight:
Dimensions: 233 mm x 160 mm x 23 mm
Weight: 500 grams
Power Consumption:
Typical power consumption is 25 watts.
Operating and Storage Conditions:
Operating Temperature: 0°C to 55°C
Storage Temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Vibration: 5G to 500 Hz
Functional Characteristics
Performance:
Boasts a 2 MB L2 cache, enhancing system performance and response time.
Expansion Options:
Offers multiple expansion options, including the 200-pin DDR SDRAM SODIMM slot and optional soldered-on board memory, allowing for customization and scalability based on specific requirements.
Interfaces:
Features an 1101.10 front panel interface and an optional G1 Gigabit front panel Ethernet port, providing a rich set of interface and connectivity options.
Reliability:
Designed for rugged industrial environments, VMIVME-7807 is suitable for applications requiring high levels of reliability and stability.
Application Scenarios
Industrial Automation: Ideal for automation systems requiring high-performance computing and robust networking capabilities.
Embedded Systems: Suitable for embedded applications where size, weight, and power consumption are critical factors.
Data Centers: Can be used in data center environments for tasks such as server monitoring, network management, and data processing.
Military and Aerospace: With its rugged design and high-performance capabilities, VMIVME-7807 is suitable for military and aerospace applications requiring reliable and secure computing solutions.
