• Processor: Intel Pentium III MMX at 600 MHz, featuring a 100 MHz front-side bus and 512 KB on-die L2 cache for efficient multitasking .
• Memory: Up to 256 MB PC-100 SDRAM for system storage, with optional 192 MB bootable CompactFlash via the secondary IDE interface .
• Interfaces:
  • VMEbus: Compliant with VME64 standards (A32/D32 addressing, MBLT/BLT protocols) for deterministic data transfer .
  • Communication: Two 10/100BASE-TX Ethernet ports, two USB 1.1 ports, and two RS-232 serial ports for connectivity .
  • Display: AGP SVGA controller supporting 1600×1200 resolution with 4 MB dedicated video memory .
• Expansion: One PMC slot for adding specialized I/O modules (e.g., analog/digital I/O, fiber-optic interfaces) .
• Power: <30W total consumption, sourced via VMEbus (+5V DC) with reverse polarity protection .
• Environmental:
  • Temperature: Operational range from -20°C to +70°C (-40°C to +85°C in extended variants) .
  • Shock/Vibration: Withstands 30g shock (11 ms duration) and 5g RMS vibration (10–500 Hz) .
  • Humidity: 5–95% RH (non-condensing) .
• Mechanical: 6U VME form factor (233×167×28 mm) with passive cooling and rugged metal enclosure .

• Multi-CPU Architecture: Transparent PCI-to-VME bridge enables operation as a system controller or peripheral CPU in multi-processor configurations .
• Real-Time Capabilities: Built-in watchdog timer and deterministic VMEbus communication for mission-critical applications .
• Software Compatibility: Supports Windows NT/2000, Linux, QNX, and VxWorks, with board support packages (BSPs) for driver integration .
• Data Security: 128 KB non-volatile SRAM for parameter storage and BIOS settings .
• Diagnostics: LED indicators for power status, Ethernet activity, and system health .
• Byte Swapping: Hardware-based endian conversion for seamless integration with mixed-endian VMEbus modules .

• Industrial Automation:
  • Controls robotic systems in automotive assembly lines, managing motion profiles and safety interlocks.
  • Monitors process variables in chemical plants via analog/digital I/O modules, ensuring compliance with ISO 9001 standards.
• Defense and Aerospace:
  • Processes radar data in airborne surveillance systems, enabling real-time threat detection and tracking.
  • Manages flight control algorithms in UAVs, integrating telemetry and navigation inputs.
• Energy Infrastructure:
  • Supervises power distribution grids via SCADA systems, providing fault detection and load balancing.
  • Controls renewable energy inverters in solar farms, optimizing energy conversion efficiency.
• Medical Equipment:
  • Processes imaging data in MRI machines, coordinating sensor inputs and image reconstruction algorithms.
  • Manages sterilization cycles in pharmaceutical autoclaves, ensuring temperature/pressure adherence to FDA guidelines.
• Transportation:
  • Controls signaling systems in metro networks, synchronizing train movements and platform screen doors.
  • Manages diagnostic systems in heavy machinery, predicting component failures via vibration analysis.
