• Processor: Intel Pentium II MMX 450 MHz (mobile module) with 32-bit addressing and 64-bit data bus, featuring a 512 KB internal L2 cache for high-bandwidth operations .
• Memory:
  • Up to 512 MB SDRAM (144-pin SODIMM) for main storage.
  • 96 MB bootable flash memory for firmware and OS storage.
  • 128 KB battery-backed SRAM for non-volatile data retention .
• I/O Interfaces:
  • Communication: Dual 10/100Base-T Ethernet ports, two RS-232 serial ports, PS/2 keyboard/mouse, and USB 1.1 .
  • Storage: Ultra DMA-33 IDE controller (supports HDD/floppy via VME P2 connector) and Fast/Wide SCSI-2 (requires P2 SCSI terminator) .
  • Expansion: Single PMC (PCI Mezzanine Card) slot compliant with IEEE P1386 for modular I/O extension .
  • Graphics: AGP SVGA controller with 4 MB SGRAM supporting resolutions up to 1280×1024 .
• Bus Support:
  • Full VMEbus compliance (P1/P2 connectors) with support for VME64 modes: A32/A24 addressing and D32/D16/D08 data transfers.
  • BLT (Block Transfer) and MBLT (Multiple Block Transfer) protocols for high-speed data streaming .
• Power: Requires +5V DC (max 5A) and ±12V DC (max 1A); typical power consumption ≤25W .
• Environmental:
  • Operating temperature: 0°C to 55°C (industrial range).
  • Mechanical: Withstands shock (50g, 11ms) and vibration (10g, 10–2000 Hz) .

• Real-Time Performance:
  • Direct Memory Access (DMA) support for deterministic data transfer, minimizing CPU intervention.
  • Three programmable 32-bit timers and software-selectable watchdog timer for critical timing tasks .
  • Hardware-based endian conversion (little/big-endian) for multi-platform compatibility .
• Software Compatibility:
  • Drivers available for Windows NT, Linux, VxWorks, QNX, and Solaris, facilitating integration with real-time OS (RTOS) .
  • Remote booting via Ethernet or flash, enabling diskless operation in distributed systems .
• Reliability:
  • Galvanic isolation on analog/digital signals to protect against ground loops.
  • Built-in bus error handling and diagnostics for fault detection .
• Flexibility:
  • PMC expansion for adding custom I/O modules (e.g., analog I/O, motion control).
  • Jumpers for hardware configuration (e.g., boot device priority, bus timing) .

• Industrial Automation:
  • Controls robotic systems and CNC machines by integrating real-time motion control algorithms with sensor feedback.
  • Manages conveyor systems and packaging equipment through high-speed I/O synchronization .
• Process Control:
  • Monitors temperature, pressure, and flow in chemical plants, providing closed-loop feedback for precision regulation.
  • Coordinates distributed control systems (DCS) in power generation facilities .
• Aerospace and Defense:
  • Implements flight simulators by processing resolver signals from hydraulic actuators and joysticks.
  • Supports radar antenna positioning systems with sub-degree accuracy for tracking and targeting .
• Medical Equipment:
  • Processes physiological signals in diagnostic devices (e.g., MRI scanners) and controls robotic surgical arms with sub-millimeter precision .
• Transportation:
  • Manages railway signaling systems by monitoring resolver-based track switch positions.
  • Controls motorized door systems in metro trains for safe, reliable operation .
