• Processor: Intel Pentium MMX with clock speeds of 166
• , 200, or 233 MHz, featuring 32-bit addressing and a 64-bit data bus for efficient multitasking.
• Memory:
  • 8 MB bootable flash on secondary IDE for firmware storage and system initialization.
  • 32 KB battery-backed SRAM for critical data retention during power interruptions.
  • Up to 128 MB SDRAM via 168-pin DIMM for program execution and data processing.
• Graphics: 64-bit PCI SVGA controller with 2 MB SGRAM supporting resolutions up to 1280×1024 for graphical user interfaces.
• Networking: Onboard Fast Ethernet controller supporting 10BaseT and 100BaseTX interfaces for high-speed network connectivity.
• Interfaces:
  • PS/2 ports for keyboard and mouse input on the front panel.
  • Byte-swapping hardware for seamless data interfacing between little-endian and big-endian systems.
• Bus Compatibility: VME64 compliant (32-bit address/data bus, 40 MHz clock) for integration with VMEbus backplanes.
• Power: Requires +5V DC (2.5A max) and +12V DC inputs; typical power consumption ≤15W under full load.
• Environmental:
  • Operating temperature: -40°C to 85°C (extended industrial range).
  • Compliance: Meets EMI/EMC standards (EN 61000-6-2/3) and withstands shock (50g) and vibration (10g, 10–2000 Hz).

• Real-Time Performance: Supports deterministic task scheduling under real-time operating systems (RTOS) like VxWorks, Linux, and QNX, ensuring low-latency control for critical applications.
• Software Transparency: BIOS and drivers enable plug-and-play functionality, reducing integration complexity for legacy and modern systems.
• Data Handling: Hardware-based byte-swapping eliminates software overhead when interfacing with mixed-endian systems, enhancing data transfer efficiency.
• Diagnostics: Onboard LED indicators for power, bus activity, and system status; register-based fault reporting for remote health monitoring.
• Expandability: Single-slot 6U VME form factor allows integration into compact systems while supporting future upgrades via VMEbus peripherals.
• Redundancy: Compatible with hot-swap backplanes, enabling module replacement without system downtime in redundant configurations.

• Industrial Automation: Used in smart factories to control PLCs, robotics, and conveyor systems, leveraging its real-time processing for synchronization and quality control.
• Aerospace and Defense: Implements flight simulators and avionics testing platforms, processing sensor data and telemetry in distributed computing nodes.
• Medical Systems: Supports real-time image reconstruction in MRI/CT scanners by managing high-speed data exchange between imaging hardware and workstations.
• Energy Management: Manages grid-scale monitoring in smart grids, coordinating power distribution and renewable energy integration across geographically dispersed nodes.
• Transportation: Controls signaling systems in railways and metro networks, processing track occupancy sensors and activating safety interlocks.
