• Input/Output Architecture:
  • 128-bit TTL-compatible channels configured as discrete digital inputs or outputs, supporting 5V DC logic levels with ±20% tolerance.
  • Dual 64-pin DIN 41612 connectors for signal termination, enabling daisy-chain or point-to-point wiring.
  • Data Transfer Modes: 8-bit or 16-bit transfers via VMEbus, with addressable access to any short supervisory or non-privileged I/O map.
• Isolation:
  • Galvanic isolation between I/O channels and VMEbus to protect against ground loops and voltage surges.
• Electrical:
  • Power: +5V DC (current consumption dependent on I/O activity), sourced via VMEbus with reverse polarity protection.
  • Output Drive: 24 mA sink capability per channel for driving loads like relays or LEDs.
• Environmental:
  • Operating Temperature: -40°C to +85°C, suitable for extended industrial and military applications.
  • Mechanical: 6U VME form factor (3U height) with rugged metal enclosure, compliant with shock (50g) and vibration (10g) standards.

• Signal Conditioning:
  • Individual Port Direction Control: Jumpers for configuring each port as input or output, enabling mixed I/O configurations.
  • Real-Time Loopback Testing: Built-in diagnostic capability to verify signal integrity and connectivity.
• Error Handling:
  • Open/Short Circuit Detection: Monitors thermocouple integrity with status flags for real-time fault reporting.
  • Overvoltage Protection: Transient protection up to 30V DC on input lines.
• Configuration Flexibility:
  • 12 DIP Switches: Define address mapping for short data I/O, allowing unlimited customization of VMEbus addressing.
  • Alternating Grounds: Mitigates noise interference by alternating ground references on I/O pins.
• Reliability:
  • Hot-Swap Capability: Module replacement without system shutdown, ensuring continuous operation.
  • LED Indicators: Provides visual feedback for channel status and power health.

• Industrial Automation:
  • Manufacturing Machinery: Controls robotic arm movements and monitors limit switches in CNC machining centers.
  • Packaging Lines: Manages conveyor belt synchronization and product sorting via proximity sensors.
• Energy Infrastructure:
  • Substation Monitoring: Supervises circuit breaker status and relay controls for grid stabilization.
  • Renewable Energy: Coordinates inverter switching and battery management in solar and wind farms.
• Transportation Systems:
  • Rail Signaling: Controls track switches and monitors train presence via inductive loops.
  • Aerospace Testing: Validates avionics systems in environmental chambers by simulating sensor inputs.
• Defense and Security:
  • Missile Guidance: Processes radar trigger signals and manages launcher interlocks.
  • Surveillance Systems: Coordinates camera pan/tilt mechanisms and access control in perimeter security.
• Process Control:
  • Chemical Reactors: Monitors safety interlocks and valve positions during batch production.
  • Pharmaceutical Cleanrooms: Ensures compliance with ISO standards by managing HEPA filter statuses.
