GE PMC-5565PIORC-210000

1. Technical Specifications

  • Memory Capacity: 256 MByte SDRAM .
  • Interface Type: PMC (PCI Mezzanine Card) .
  • Transmission Mode: Multimode fiber optic .
  • Transmission Distance: Up to 300 meters .
  • Data Transfer Rate:
    • 43 MB/s (for 4-byte packets) to 174 MB/s (for 64-byte packets) .
    • Serial baud rate: 2.12 Gbaud .
  • Network Scalability: Supports up to 256 nodes .
  • Compliance: RoHS (Restriction of Hazardous Substances) certified .
  • Error Handling: Includes error detection and redundant transfer mode for reliability .
WhatApp
WeChat

Detailed content

2. Functional Features

  • Reflective Memory Technology:
    • Automatically synchronizes data across all nodes in real time. Data written to local memory is instantly broadcast to all other nodes via optical fiber .
    • Near-deterministic latency (microsecond-level synchronization) .
  • Zero Software Overhead:
    • Operates without CPU involvement or complex network protocols, reducing system latency .
  • Dual DMA Channels: Optimizes data throughput during peak loads .
  • Inter-Node Interrupts: Any node can trigger interrupts across the network .
  • FIFO Buffering: Maintains high data throughput during burst transmissions .

3. Application Scenarios

  • Real-Time Simulation Systems:
    • Aircraft/ship/submarine simulators .
    • Power plant and engine test stand simulations .
  • Industrial Automation:
    • Aluminum rolling mills, process control systems, and high-speed data acquisition .
    • PLC (Programmable Logic Controller) integration .
  • Critical Infrastructure:
    • Nuclear power plants, rocket engine testing (supports long-distance transmission via single-mode variants) .
  • Data-Intensive Environments:
    • Applications requiring large datasets (e.g., 256MB memory for heavy data transmission) .

4. Ordering & Variants

  • Model Differentiation:
    • The suffix -210000 denotes 256MB memory + multimode fiber .
    • Other variants include -211000 (256MB + single-mode fiber) and -110000 (128MB + multimode) .
  • Compatibility: Fully compatible with GE’s reflective memory ecosystem (e.g., PCI/CPCI/PCIE versions) .

5. Additional Notes

  • Warranty: Typically 1 year, based on factory standards .
  • Regulatory Certifications: VCCI Class A (Japan), CISPR 22 Class A (EMC) .
