GE IS220PDIOH1A

Technical Specifications
Specification Details
Manufacturer General Electric (GE)
Model Number IS220PDIOH1A
Bus Type VMEbus
I/O Points
– Digital Inputs 16 points
– Digital Outputs 16 points
– Relays 2 (with options for additional relay output terminals)
– Analog Inputs 1 point (range: -10 V to +10 V)
Data Transfer Rate Up to 10 MHz
Power Supply +5 V, +12 V, -12 V

WhatApp
WeChat

Detailed content

Technical Specifications

Specification Details
Manufacturer General Electric (GE)
Model Number IS220PDIOH1A
Bus System VMEbus
I/O Points
– Digital Inputs 16 Points
– Digital Outputs 16 Points
– Analog Inputs 1 Point (Range: -10 V to +10 V)
Relays 2 Relays
Data Transfer Rate Up to 10 MHz
Power Supply Voltage +5 V, +12 V, -12 V
Power Consumption Approximately 5 W
Operating Temperature -40°C to +85°C
Protection Rating IP30
Dimensions 233 mm x 167 mm
Weight Approximately 1 kg

Functional Characteristics

  • High Isolation Voltage: Offers a high isolation voltage of up to 1500V between field signals and the system, providing excellent electrical noise immunity.
  • Pluggable Design: Enables plug-and-play operation, simplifying installation and maintenance.
  • Channel Isolation: Channels are isolated from each other, ensuring that a fault in one channel does not affect the rest of the module.
  • Redundant Power Supply: System power is supplied by an independent +24V power source, ensuring complete isolation from the system’s main power supply.
  • Data Output Confirmation: The DO (Digital Output) channels employ a data output readback confirmation mechanism to ensure reliable data transmission.
  • Self-Protection: Incorporates self-protection features, such as overcurrent protection, to prevent damage in case of internal faults.
  • Configurable Redundancy: Supports various redundancy configurations, including single and dual redundancy, enhancing system reliability.
  • Programmability and Scalability: Offers programmability and scalability, allowing it to integrate seamlessly with other industrial automation and control systems.

Application Scenarios

  • Industrial Control Applications: The IS220PDIOH1A is suitable for a wide range of industrial control applications, including motor control, valve regulation, process automation, and machine control systems.
  • Distributed Control Systems (DCS): It can be integrated into DCS environments, where it functions as a critical I/O module for data acquisition and control.
  • Harsh Environments: With its robust design and high protection rating, the IS220PDIOH1A is suitable for use in harsh industrial environments, such as those with high temperatures, dust, or humidity.
  • Automation and Monitoring: Used to automate and monitor various processes, ensuring efficient and reliable operation of industrial equipment and machinery.
