GE IC800VMM20MNKS

Technical Specifications

  • Control Axis: Single-axis control for linear or rotational motion systems.
  • Output Type: Pulse train output (supports differential and single-ended signals).
  • Max Output Frequency: 2 MHz for high-speed motion control.
  • Position Control: Supports absolute and relative positioning with ±1-micron accuracy.
  • Speed Control: Range of 0.01 mm/min to 1000 mm/min with adjustable acceleration/deceleration profiles.
  • Torque Control: 0–100% rated torque adjustment for dynamic load handling.
  • Input Power: 24VDC (wide input range: 18–30VDC).
WhatApp
WeChat

Detailed content

  • Communication Protocols: EtherCAT, Profinet, Ethernet/IP for seamless integration with PLCs or HMIs.
  • I/O Interfaces: Multiple digital/analog inputs/outputs for external sensor and actuator connectivity.
  • Programming: Supports IEC61131-3 standards (ladder logic, structured text, function blocks).
  • Environmental Rating: IP65 front panel for dust/water resistance; operating temperature: -20°C to +60°C.

Key Functional Characteristics

  • High-Speed Motion Control: Real-time processing with sub-millisecond latency for precise trajectory execution.
  • S-Curve Acceleration: Reduces mechanical stress by minimizing abrupt starts/stops.
  • Multi-Protocol Support: Compatible with major industrial Ethernet standards for flexible system integration.
  • Modular Design: DIN-rail mountable for easy installation in control cabinets.
  • Diagnostics & Monitoring: Built-in fault detection and real-time status feedback via LED indicators or software tools.
  • Safety Features: Emergency stop (E-stop) and overcurrent protection compliant with industrial safety standards.

Application Scenarios

  • Industrial Automation: Controls conveyor systems, assembly robots, and CNC machine tooling for precise material handling.
  • Packaging Machinery: Manages labeling, filling, and sealing processes with synchronized motion profiles.
  • Textile Equipment: Regulates yarn tension and fabric feeding in weaving or knitting machines.
  • Printing Presses: Ensures accurate registration control in high-speed printing applications.
  • Robotics: Drives joint actuators in robotic arms for tasks like welding, painting, or pick-and-place operations.

Advantages

  • Scalability: Modular architecture allows future upgrades without replacing the entire system.
  • Reliability: Designed for 24/7 operation in harsh environments with minimal maintenance.
  • Interoperability: Works with third-party devices via open protocols like EtherCAT and Profinet.
  • Energy Efficiency: Optimized power consumption reduces operational costs in continuous-duty applications.
