Control Resolution

• Position: 20-bit
• Speed: 0.1 RPM

I/O & Interfaces

• Digital I/O: 8+ channels
• Analog I/O: Configurable (0–10V/4–20mA)
• Communication: RS-232/485, Ethernet/IP, Modbus, CANopen

Environmental Ratings

• Operating Temp: -20°C to +70°C
• Protection Class: IP65
• Humidity: 10–90% non-condensing

Physical Dimensions

• Size: 190 × 70 × 30 mm
• Weight: 1.5 kg
• Mounting: DIN rail

Functional Features

Precision Motion Control

• Sub-millisecond response via PID/fuzzy logic algorithms
• Saliency-based rotor positioning for accuracy

Safety & Diagnostics

• Real-time fault detection (overloads, short circuits)
• Motor thermal protection

Integration Flexibility

• Programmable logic via MotionLink® software
• Multi-protocol support (Ethernet/IP, CANopen, Modbus)

Modular Expandability

• Compatible with Genius I/O modules for +42 I/O channels

Application Scenarios

Industrial Automation

• CNC spindle control
• Robotic arm joint synchronization

Process Control

• High-speed packaging conveyors
• Valve positioning in oil/gas pipelines

Energy Infrastructure

• Pump speed modulation in water treatment
• Solar tracker positioning

Critical Systems

• Aerospace actuator control

Compatibility

Controllers

• GE PACSystems RX3i
• Siemens S7-300, Schneider Modicon

Motors

• GE MTR series
• Brushless AC/DC servos

Certifications

• CE, RoHS, UL/cUL, IEC 61131-2

Key Advantages

Performance

• 20-bit positioning (vs. 16-bit in competitors)
• 200 Hz control frequency

Robustness

• IP65 protection for dust/liquid resistance
• -20°C to +70°C operational range

Lifecycle Value

• Field-upgradable firmware
• 3-year extendable warranty

Procurement Notes

• Pricing: 2,000 USD
• Lead Time: 3–5 days (stock units)
• Critical: Verify CE certification to avoid counterfeits
