Display: 15 – inch projected capacitive multi – touch TFT LCD display, with a resolution of 1024 x 768 pixels.
Operating System: Windows Embedded Compact 7.
Communication Interfaces: Two Ethernet interfaces, one RS232 port, one RS485 port, and three USB interfaces (2x USB 2.0 Type – A, 1x USB 2.0 Mini Type – B).
Power Supply: 12/24 VDC.
Power Consumption: 30 watts.
Dimensions: 399 x 323 x 70 millimeters (15.7 x 12.7 x 2.7 inches).
High – Performance Processing: The 1 – GHz ARM Cortex A8 – based processor ensures fast and efficient operation, capable of handling complex industrial control and visualization tasks.
Multi – Touch Display: The projected capacitive multi – touch screen provides an intuitive and user – friendly operation interface, allowing for easy interaction with the device.
Rich Communication Interfaces: With multiple Ethernet, serial, and USB ports, it can easily connect to various industrial devices and systems, enabling seamless data communication and integration.
Integrated Software Functions: It supports the use of Proficy Process System software and can function as an operator interface, data historian, and more. It also has a fully functional HTML5 browser and multimedia access capability with the Windows EC7 operating system, allowing users to access the internet, view videos, and compile reports.
Reliable Data Storage: The battery – backed SDRAM ensures that important data is not lost during a power failure.
Application Scenarios
Industrial Automation: Widely used in manufacturing plants to monitor and control production lines, such as the operation status of machine tools and the adjustment of conveyor belt speeds.
Process Control: In industries such as chemical, power, and oil, it is used to monitor and control various process parameters, such as temperature, pressure, and flow rate.
Environmental Protection: Applicable in environmental protection projects, such as monitoring and controlling wastewater treatment processes and air quality monitoring systems.
