Display Size: 6 – inch diagonal, with an actual display size of 5.75 inches (14.6 centimeters).
Resolution: 320 x 240 pixels.
Touchscreen Type: 12 – bit resistive touchscreen.
Processor: Intel Xscale PXA255, with a clock speed of 200 MHz.
Memory: 32 MB of internal memory (including flash and DRAM), and 512 KB of SRAM with battery backup.
Power Supply: Input voltage range is 12 – 30 volts DC.
Communication Ports: Usually includes RS232 and RS485 serial ports, and may also have an Ethernet port.
Dimensions: Approximately 4.86 inches (126 millimeters) in height, 6.14 inches (156 millimeters) in width, and 2.026 inches (51.5 millimeters) in depth.
Weight: About 2.5 pounds (1.16 kg).
Operating Temperature: – 10 to 60 degrees Celsius.
Monochrome Display: The monochrome display with 256 shades of grey can clearly show various process information and device status indicators, which is convenient for operators to view relevant data.
Convenient Operation: The 12 – bit resistive touch – screen interface enables operators to easily input commands and adjust parameters, with high – sensitivity operation.
Reliable Data Storage: The battery – backed SRAM ensures that important data is not lost during a power failure, ensuring the integrity of data.
Versatile Communication: With RS232, RS485 and other communication ports, it can be connected to various industrial devices such as PLCs, sensors, and actuators to realize data exchange and control.
Easy Programming: It can be programmed using Proficy View – Machine Edition software, which is convenient for users to develop application programs.
Application Scenarios
Industrial Automation: In manufacturing plants, it can be used to monitor and control production lines, such as the operation status of machine tools and the speed adjustment of conveyor belts.
Process Control: In the chemical, power and other industries, it is used to monitor and control various process parameters, such as temperature, pressure, and flow rate.
Robotics: It can be applied in robotic control systems to achieve intuitive operation and monitoring of robots.
Food and Beverage Processing: In the food and beverage processing industry, it is used to monitor and control the production process to ensure product quality and production efficiency.
