GE IC754VBI12CTD-CD

Technical Specifications

  • Display: 12-inch color TFT LCD with a resolution of 800 x 600 pixels and 65,536 colors for clear visualization.
  • Touch Technology: Supports touch input via fingertips or a stylus, enabling intuitive operation.
  • Processor: ARM Cortex-A8, 800MHz for efficient data processing.
  • Memory: 256MB RAM and 512MB Flash storage (expandable).
  • Operating System: Windows CE 6.0, compatible with GE Proficy software for configuration and programming.
WhatApp
WeChat

Detailed content

  • Communication Interfaces:
    • 1 x Ethernet port (10/100 Mbps) for network connectivity.
    • 2 x RS-232 ports and 1 x RS-485 port for serial communication.
    • 1 x USB 2.0 port (Host/Device) for data transfer and peripheral connectivity.
  • Power Requirements: 24VDC ±10%, with a power consumption of ≤25W.
  • Operating Conditions:
    • Temperature: -20°C to +60°C (operating), -30°C to +70°C (storage).
    • Humidity: 5% to 95% RH (non-condensing).
  • Enclosure Rating: IP65 (front panel) and NEMA 4/4X for dust and water resistance.
  • Certifications: CE, UL, cUL, and optional ATEX certification for explosive environments.

Key Functional Characteristics

  • User-Friendly Interface: Provides a familiar Windows CE environment with standard commands and functions, such as file transfer, remote access, and PDF viewing.
  • High-Resolution Display: The 12-inch TFT LCD supports customizable graphical displays, trend charts, and alarm management for efficient operation.
  • Multi-Language Support: Enables dynamic language switching (e.g., English, Chinese, German) for global usability.
  • Data Logging and Analysis: Supports historical data recording and viewing when used with GE Proficy Machine Edition 5.0 or higher.
  • Robust Design: Withstands vibrations, shocks, and EMI, making it suitable for demanding industrial environments.
  • Remote Diagnostics: Facilitates maintenance and troubleshooting through remote access capabilities.

Application Scenarios

  • Factory Automation: Controls and monitors assembly lines, robotic systems, and CNC machines.
  • Process Control: Visualizes and regulates parameters in chemical, pharmaceutical, or food and beverage production.
  • Energy Management: Integrates with power generation or distribution systems for real-time monitoring.
  • Water/Wastewater Treatment: Tracks pump stations, filtration processes, and chemical dosing units.
  • Building Automation: Supports HVAC, lighting, or security systems in smart infrastructure projects.
  • Oil & Gas: Monitors pipeline parameters or drilling operations in remote locations.
