• Dimensions: 6U height × 21 HP width × 233 mm depth
• Weight: Approximately 2.3 kg
• Operating Temperature: -20°C to 60°C
• Storage Temperature: -40°C to 85°C
• Humidity Tolerance: 5% to 95% RH (non-condensing)
• Certifications: CE, UL, and other industrial compliance standards

Key Functional Characteristics

• Real-Time Control:
  • The 700 MHz Pentium III processor enables precise real-time control of machines and processes, with a standard execution speed of 0.14 ms per 1000 Boolean contacts.
• High-Speed Communication:
  • Dual Ethernet ports support high-speed data transfer and integration with industrial networks using protocols like Modbus/TCP, PROFIBUS DP, DeviceNet, and Ethernet Global Data (EGD).
  • Serial ports facilitate communication with legacy devices and support protocols such as Modbus RTU, SNP, and serial I/O.
• Multi-Tasking Capability:
  • The CPU can simultaneously execute multiple control tasks and data processing operations, enhancing system efficiency and responsiveness.
• Programming Flexibility:
  • Supports ladder logic and C programming, allowing users to develop complex control algorithms tailored to specific applications.
• Data Storage and Management:
  • RAM and NVRAM provide ample space for storing user programs, configuration settings, symbolic variables, and register data.
  • The operating system firmware is stored in NVRAM, ensuring reliable operation even during power interruptions.
• Self-Diagnostic Functions:
  • The CPU performs comprehensive self-checks during startup and operation, with LED indicators displaying system status and fault conditions for easy troubleshooting.
• Modular Design:
  • Designed for standard VME64 backplane integration, enabling seamless expansion with additional I/O modules, communication modules, and other peripherals.

Application Scenarios

• Manufacturing Automation:
  • Controls and optimizes production lines, assembly processes, and material handling systems in automotive, electronics, and consumer goods manufacturing.
• Process Control:
  • Manages and regulates industrial processes such as oil and gas refining, chemical processing, power generation, and water treatment.
• Building Automation:
  • Monitors and controls HVAC systems, lighting, and security systems in commercial and industrial buildings.
• Transportation Systems:
  • Supports traffic control systems, railway signaling, and vehicle automation in smart transportation infrastructure.
• Energy Sector:
  • Ensures reliable operation of power grid control systems and critical infrastructure in the energy industry.
• Other Industries:
  • Applicable in food and beverage processing, semiconductor manufacturing, packaging, textile, and printing industries.
