Technical Specifications

• Manufacturer: General Electric (GE)
• Model: IC693TCM302
• Input Voltage Range: 12-48 VDC (may vary based on external power usage, with a rated voltage of 18-36 VDC when using external power)
• Output Voltage Range: 5 VDC (for internal operations); Output ports for control purposes may have different voltage ranges (e.g., 18-30 VDC for control outputs)
• Output Current: Maximum 10A (for specific output ports, depending on application)
• Efficiency: Greater than 90%
• Size: 170mm x 105mm x 32mm
• Weight: Approximately 120g
• Operating Temperature: -20°C to +50°C
• Storage Temperature: -40°C to +70°C
• Humidity: 5% to 95% relative humidity (non-condensing)
• CPU: 32-bit RISC processor

Functional Characteristics

• Temperature Input: The IC693TCM302 features input ports for connecting temperature sensors, such as thermocouples and resistance temperature detectors (RTDs).
• Data Processing: The module processes temperature data from sensors, including linearization and calibration, to ensure accurate temperature measurements.
• Alarm Function: It may incorporate alarm functionality, generating signals when temperatures exceed predefined limits, notifying operators or triggering control actions.
• Control Output: Equipped with control output ports, the module can connect to actuators or control devices to execute actions based on measured temperatures, e.g., starting/stopping cooling systems or controlling heating elements.
• Communication Interface: The IC693TCM302 communicates with the PLC CPU via the backplane bus, enabling data exchange and integration with the PLC’s control logic.
• Configuration and Programming: The module can be configured and programmed using PLC programming software to meet specific application requirements and implement customized temperature control logic.
• Reliability and Durability: As an industrial control device, the IC693TCM302 is designed for high reliability and durability, ensuring stable operation in harsh industrial environments.

Application Scenarios

The GE IC693TCM302 temperature control module is widely used in various industrial applications requiring precise temperature monitoring and control. Some common scenarios include:

• Manufacturing: In factories and manufacturing facilities, where temperature control is critical for maintaining process stability and product quality.
• Process Industries: In chemical, petrochemical, and other process industries, where temperature regulation is essential for safe and efficient operations.
• Food and Beverage: In food processing and packaging lines, ensuring that products are maintained at the correct temperatures during processing and storage.
• HVAC Systems: In heating, ventilation, and air conditioning (HVAC) systems, controlling indoor temperatures to maintain comfort levels.
• Power Generation: In power plants, monitoring and controlling the temperature of critical components to ensure safe and efficient operation.
