GE IC693MDL753

  • Operating Voltage: 12 or 24 volts DC.
  • Output Voltage Range: 10.2 to 28.8 volts DC.
  • Output Current: 0.5 amps maximum per output point, 4 amps maximum per group.
  • Number of Outputs: 32 individual output channels, grouped into four isolated groups of eight.
  • Isolation: 1,500 V between field side and logic side, 250 V between groups.
  • Response Time: 0.5ms max. on and off response time.
  • Power Consumption: 260 ma max. from 5v bus on backplane (13 ma + 3 ma / point on + 4.7 ma / led).
  • Operating Temperature Range: -10 °C to +55 °C.
  • Storage Temperature Range: -40 °C to +70 °C.
  • Humidity Range: 5% to 95% non – condensing.
  • Dimensions: Width x Depth x Height (mm): 144 x 85 x 73.
  • Weight: Approximately 0.2 kg.
WhatApp
WeChat

Detailed content

Functional Features



  • Positive Logic Output: It adopts positive logic, where high voltage represents the “on” state and low voltage represents the “off” state.
  • Multiple Output Channels: With 32 discrete output channels, it can control multiple devices simultaneously. The channels are grouped into four isolated groups, which allows for flexible control and isolation of different loads.
  • Over – current Protection: Each output point has a maximum current limit of 0.5 amps, and each group has a maximum current limit of 4 amps, which can protect the connected devices from over – current damage.
  • Status Indication: LED indicators are provided on the module to display the on/off status of each output point, which is convenient for monitoring and troubleshooting.
  • Communication Compatibility: It is compatible with various communication protocols, such as RS – 485, DeviceNet, and Ethernet/IP, which facilitates seamless integration with existing control systems.



Application Scenarios



  • Manufacturing Industry: It can be used in manufacturing automation production lines to control the operation of motors, solenoid valves, and other actuators.
  • Packaging Industry: Applicable in packaging machinery to realize the control of various actions in the packaging process.
  • Logistics Industry: Used in logistics transportation and sorting systems to control equipment such as conveyor belts and lifting devices.
  • Process Control Industry: Suitable for process control systems, such as chemical, pharmaceutical, and food processing industries, to control the opening and closing of valves, pumps, and other equipment.
