Output Current: 0.5A per point, 4A per group, and a maximum of 3A per group common pin
Inrush Current: 5.4A for 10ms
On/Off Response Time: Maximum 0.5ms
Communication Protocol: DeviceNet
Data Rates: Supports 125K, 250K, and 500K Baud
Backplane Current Consumption: 450mA at 5V DC (typical)
Operating Temperature Range: 0℃ – 60℃
Storage Temperature Range: – 40℃ – 85℃
Mounting Location: In the main rack of Series 90 – 30 (any slot except slots 0 and 1), and in the main rack of PACSystems RX3i (any slot except slot 0)
High – speed Communication: It supports high – speed communication, enabling fast data transfer and response times to meet the requirements of real – time control systems.
Powerful Master Function: As a DeviceNet master, it is responsible for controlling and monitoring slave devices on the network, exchanging data with them, monitoring their status, and sending control commands.
Easy Configuration and Diagnosis: It provides configuration tools and diagnostic functions, which can be used to set network parameters, configure slave devices, and monitor network status, helping to simplify system configuration and troubleshooting.
Good Compatibility: It can be used in conjunction with other GE Series 90 – 30 PLC modules to achieve larger – scale and more complex control systems.
Dual – mode Operation: The module can operate in both master and slave modes simultaneously, and the fault behavior during communication loss can be configured to provide an acceptable system response.
Firmware Upgradeable: It is equipped with upgradeable firmware, allowing module updates and error fixes to be downloaded through the RS232 service port.
Application Scenarios The GE IC693DNM200 – CD is mainly used in industrial automation and control systems, such as in the automation production lines of the manufacturing industry, where it can be used to control the operation of various equipment; in the power industry, it can be used in power distribution systems to monitor and control the status of electrical equipment; and in the chemical industry, it can be used to monitor and control key parameters in the production process, etc.
