Technical Specifications

• Slots Configuration:
  • Power Slot: A unique slot designed to accommodate a power module, located on the left side of the baseplate. This slot is not numbered.
  • CPU/Special Option Slot (Slot 1): This slot is specifically designed to house a CPU module or a special option module such as the FIP Remote I/O Scanner (IC693BEM330). Marked as “CPU/1.”
  • I/O or Option Slots (Slots 2 and above): Slots 2 and above have unique dimensions and types, supporting I/O or option modules.
  • Expansion Connector: A 25-pin D-sub female connector located at the right end of the baseplate, allowing connection to expansion or remote baseplates.
• Compatibility:
  • Compatible with standard 90-30 series I/O modules and specialized modules.
  • Supports CPU modules such as those from the 331, 340, 341, and 350 series or higher.
• Power Requirements:
  • Requires a dedicated power module for operation.
• Physical Dimensions:
  • Dimensions and weight may vary based on specific models and configurations, but generally aligns with the standard 90-30 series form factor.

Functional Characteristics

• Modularity:
  • Offers a modular design, allowing for easy replacement or upgrade of individual components such as the CPU or I/O modules.
  • Enables expansion via additional baseplates connected through the expansion connector.
• Communication Capabilities:
  • Integrated communication interfaces on the CPU baseplate, which can be optionally configured for Ethernet or ARCNET.
  • Supports FBP (FieldBus Plug) bus adapters for communication and distributed I/O expansion.
• Programming Flexibility:
  • Provides rich programming interfaces and languages, facilitating fast and efficient development cycles.
  • Enables users to program and configure the PLC for various automation tasks.
• I/O Versatility:
  • Supports both analog and digital I/O modules, with options for different signal types and wiring configurations.
  • Allows for pre-wiring of I/O without the need for actual modules.

Application Scenarios

• Industrial Automation:
  • Ideal for use in various industrial automation systems, where precise control and monitoring of equipment and processes are required.
  • Can be integrated into manufacturing lines, process control systems, and machine automation applications.
• Machine Control:
  • Suited for controlling machines and equipment in factories, plants, and other industrial settings.
  • Enables automated sequences, monitoring of sensor inputs, and control of actuators and motors.
• Process Control:
  • Used in process industries such as chemicals, oil and gas, food and beverage, and water treatment, where precise control of process variables is crucial.
