Power Supply: It requires 5V DC from the backplane.
Operating Temperature: The operating temperature range is 0°C to 55°C.
Relative Humidity: 5% to 95% non – condensing.
Module Size: It is a single – slot module that can be installed in any Series 90 – 30 baseplate.
Communication Interface: It can communicate with other devices through the backplane of the Series 90 – 30 PLC.
Cable Connection: A 24 – pin I/O cable is used for building custom – length cables, and there are three different kits available: crimp wire receptacle, solder eyelet receptacle, and IDC (ribbon) receptacle.
Dual – Axis Control: It has 2 – axis motion control functionality, which can independently control the motion of two axes, meeting the needs of applications requiring multi – axis control.
Programmable Modes: The module can operate in either follower or standard mode. In follower mode, it provides high – performance “electronic gearing”, which is very useful for slave – master applications. Users can select the preferred mode in the configuration software.
High – Performance Integration: It combines high – performance motion control with PLC logic – solving capabilities, enabling complex motion control tasks to be integrated with PLC control logic in one system.
Motion Program Storage: A maximum of 10 motion programs can be created and stored in the APM module.
Application Scenarios
Industrial Automation: Widely used in various industrial automation production lines, such as controlling the movement of conveyor belts, the position of robotic arms, etc.
Machine Tool Control: In machine tools, it can be used to precisely control the movement of the spindle and feed axes to achieve high – precision machining.
Packaging Machinery: Used in packaging machinery to control the movement and position of packaging materials, improving production efficiency and packaging quality.
Printing Machinery: In printing machinery, it can precisely control the movement of the printing head and paper to ensure printing quality.
