Output Voltage: 0 – 125VDC (nominal values of 5V, 24V, 125VDC); 0 – 265VAC (47 – 63Hz), with nominal values of 120VAC and 240VAC.
Load Current per Point: 2.0A for 5 – 265VAC; 2.0A for 5 – 30VDC; 0.2A for 31 – 125VDC. The minimum load current per point is 10mA.
Response Time: The on – time and off – time are both 10ms.
Isolation: Input to logic isolation is 250VAC continuous and 1500VAC for 1 minute; group – to – group isolation is 250VAC continuous and 1500VAC for 1 minute. Each output is individually isolated.
Power Consumption: The maximum 5V backplane current consumption is 490mA.
Dimensions: 5 cm x 11 cm x 6.68 cm (excluding the height of the carrier or the mating connectors).
High – reliability Relay Output: The module uses relays with fixed coils and moving armatures, and the contact material is silver alloy. This ensures high – reliability and long – life operation. Each output contact is individually isolated, which can effectively prevent electrical interference.
Wide – range Voltage Adaptability: It can support a wide range of output voltages, including DC and AC, which makes it suitable for various types of load devices.
LED Indication: There is one LED per point, which can display the on/off state of each output point, facilitating users to monitor the working status of the module.
No Output Leakage Current: When the contact output is in an open state, there is no output leakage current, ensuring the accuracy and safety of the control system.
Application Scenarios
Factory Automation: In automated production lines, it can be used to control the start – stop of motors, the opening and closing of valves, and the indication of status lights, such as in assembly lines, packaging lines, etc.
Process Industry: In industries such as chemical, petroleum, and pharmaceutical, it can be used to control the operation of equipment such as agitators and heaters in chemical reaction kettles, as well as the switching of valves in the pipeline system, ensuring the stable operation of the production process.
Power Systems: In power generation, transmission, and distribution systems, it can be used to control the on – off of circuit breakers and relays, and realize the remote control and automation management of power equipment.
Environmental Protection Industry: In sewage treatment equipment, it can be used to control the operation of pumps, fans, and other equipment, so as to achieve the automation control of the sewage treatment process.
