Technical Specifications:

Output Points: 16 digital output points
Output Type: Relay output
Output Current: 2A per point
Output Voltage: 24VDC (with a range of 24VDC to 250VAC for load voltage)
Load Current Range: 0.1A to 2A
Switching Speed: Less than 1ms
Operating Temperature Range: -40°C to 70°C
Power Supply Voltage: 24VDC
Size: 110mm x 66.8mm x 50mm
LED Indicators: Each output point has an LED, as well as “OK” and “FLD PWR” LEDs for status indication
Backplane Current Consumption: 5V, 45mA
External Power Supply: 10.2VDC to 30VDC, nominal 12/24VDC
Functional Characteristics:

High Reliability: Manufactured with high-quality relays, ensuring long-term reliable operation.
High Speed: With a switching speed of less than 1ms, it meets the requirements of high-speed control applications.
High Current Capability: Each output point can provide 2A of output current, capable of driving various loads.
Easy to Use: Comes with clear wiring diagrams and programming guides, simplifying installation and use.
LED Status Indication: Provides LED indicators for each output point, facilitating troubleshooting and monitoring.
Rack-Mountable and Compact Design: Features a compact design with rack-mounting options, allowing for easy integration into PLC systems.
Hot-Swappable: Enables replacement without interrupting field wiring, reducing downtime.
Application Scenarios:

Motor Control: In production lines, the IC200MDL740E can be used to control motor start/stop and direction.
Valve Control: In chemical plants, it can control the opening and closing of valves.
Drive Activation: In dashboards, it can drive indicators to display equipment status.
Process Control: In chemical plants, it can regulate parameters such as temperature and pressure during reactions.
Discrete Control: In production lines, it can control devices like conveyor belts and robots.
Power Systems: In power plants, it can manage the operation of generator sets.
Oil and Gas: In oil and gas extraction processes, it can oversee the operation of wells.
Water Treatment: In water treatment plants, it can regulate water treatment processes.
Compatibility and Integration:

Compatible with the IC200CHS series of insertable relay sockets, facilitating integration into existing VersaMax PLC systems.
Can be configured using appropriate software tools, allowing for flexible setup and customization to specific application requirements.
