Compatibility: Designed to work with VersaMax communication modules such as IC200BEM002 (Profibus – DP network slave module), IC200BEM103 (DeviceNet network control module).
Dimensions: 66.8 mm x 133.4 mm x 70 mm (excluding the height of the DIN rail).
Operating Temperature: 0 to 60 °C.
Storage Temperature: – 40 to 85 °C.
Network Data Rate: For modules like IC200BEM002 connected to it, the network data rate can range from 9.6 Kbaud to 12 Mbaud.
Power Consumption: For the connected communication modules, the power consumption is up to 460 mA at 5 V output and up to 5 mA at 3.3 V output.
Modular Design: It has a modular structure, which allows for flexible configuration with other VersaMax modules, providing great convenience for system expansion and upgrading.
Easy Installation: It can be easily snapped onto a 7.5 mm x 35 mm DIN rail, and there is a latch hole to secure the communication module to the carrier, ensuring stable connection.
Backplane Communication: It provides a backplane connection for high – speed data exchange with the CPU, and also offers power supply to the connected communication module, ensuring the normal operation of the communication module.
Multiple Protocol Support: Supports multiple communication protocols, such as DeviceNet, Profibus – DP, and AS – I, which enhances the versatility and compatibility of the system.
Application Scenarios
Industrial Automation: Widely used in various industrial production lines, such as automotive manufacturing, electronics production, etc. It can connect different field devices to the PLC, realizing centralized control and monitoring of the production process.
Process Control: In the chemical, pharmaceutical and other process industries, it can be used to connect fieldbus – based sensors and actuators, enabling the PLC to accurately control process parameters such as temperature, pressure, and flow rate.
Power Industry: It can be applied in power generation, power distribution and other power – related systems, connecting various intelligent devices in the power grid to the control system, facilitating the monitoring and management of the power system.
