Resolution:
15-bit
16-bit
Accuracy: ±0.1%FS (Full Scale) or ±0.3%FS
Conversion Time:
<2 ms
0.4 ms
Common Mode Rejection Ratio (CMRR): >60 dB
Noise Immunity: >10 V RMS
Power Supply Voltage: 24 VDC
Operating Temperature Range: -40°C to 70°C
Relative Humidity: 5% to 95% (non-condensing)
Isolation: Input/Output Isolation
Protection: Short-circuit protection, Overvoltage protection
Dimensions: 110 mm x 66.8 mm x 50 mm (as per one source), 102 x 31 x 23 mm (as per another source)
Weight: 100 grams (approx.)
Functional Characteristics:

High Resolution: Provides high-resolution analog-to-digital conversion, ensuring accurate data acquisition.
High Accuracy: Offers high accuracy, making it suitable for precision industrial applications.
Multi-Channel Capability: With 15 input channels, it can handle multiple analog signals simultaneously.
Input Flexibility: Accepts both current (4-20 mA) and voltage (-10V to +10V, depending on configuration) inputs.
Isolation and Protection: Features input/output isolation and protection mechanisms to ensure safe and reliable operation.
Fast Conversion Time: Rapid conversion time allows for real-time monitoring and control.
Diagnostic Capabilities: Can detect errors such as internal power loss and open circuits, reporting these to the CPU for indication and display.
Application Scenarios:

Industrial Automation: Ideal for collecting and processing analog signals from various sensors in industrial automation systems.
Process Control: Used in process control applications where precise monitoring and control of process variables are required.
Manufacturing: Suitable for manufacturing environments where multiple analog inputs need to be acquired and processed for real-time control.
Power Systems: Can be used in power systems for monitoring and control of electrical parameters such as current and voltage.
Testing and Measurement: Applicable in testing and measurement applications where high-accuracy analog data acquisition is necessary.
Note: The information provided is based on various sources and may vary slightly depending on the specific model, configuration, or manufacturer’s updates. For the most accurate and up-to-date information, please refer to the official GE documentation or contact GE directly.
