Detailed content
Power Rating:
Constant Torque Application: 375 HP motor, 575 VAC
Variable Torque Application: 300 HP motor, 380 VAC
Installation: External installation, dimensions must meet the worst-case switching requirements of dynamic braking IGBT
Functional Characteristics
Voltage Transient Limitation: Designed to limit voltage transients across IGBTs, ensuring stable operation under all known drive operating conditions.
IGBT Gate Driver Output Regulation: Adjusts the output of the IGBT gate driver board to match the electrical characteristics of the AT frame drive.
Interface with Power/Interface Board (IMCP): Operates through the circuit provided by the connected IMCP board, connecting via a four-pin connector.
Connector Types:
Busbar I/O Connector
DBPL Input Connector
Board Lock Connector (with varying pin numbers, terms, and descriptions)
Application Scenarios
Industrial Automation: Utilized in industrial automation systems requiring precise control of motor torque and speed, particularly in variable and constant torque applications.
Power Generation: Employed in power generation facilities, where stable and reliable control of drive systems is critical to ensure efficient operation.
Heavy Industry: Suitable for heavy-duty applications such as mining, steel production, and cement manufacturing, where high-powered motors are used extensively.
Machine Tools: Integrated into machine tools to ensure accurate and responsive control of motors, enhancing productivity and reducing downtime.
