Type:Active

Communications Protocol:Modbus RTU, DNP 3.0

Red Breaker Closed LED:Visible status indicator

Frequency:25 to 60 Hz nominal

Insulation Voltage:300 V

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states, 8 output relays

Dimensions:Approx. 18 cm W x 16.5 cm L x 21.5 cm H

Relay Mounting:Standard 19-inch panel compatible

Operating Environment:Humidity up to 90% non condensing

Overvoltage Protection:Sensitized ground current inputs

    The GE 750-P5-G5-S5-HI-A20-R-E Relay Module is designed for seamless integration into existing industrial control systems, ensuring enhanced system reliability and efficiency.

    Featuring advanced waveform capture capabilities, it monitors critical electrical parameters, enabling proactive maintenance and optimization.

    With its robust construction and versatile communication protocols, this relay module is suitable for a wide range of applications, from power distribution networks to complex automation systems.

    Key highlights include a visible red breaker closed LED, which provides immediate feedback on the operational status, and enhanced insulation voltage protection against overvoltage events.

    The compact design allows for efficient space utilization and easy mounting, making it a practical choice for both new installations and retrofits.

    Certified for operation in demanding environments, the GE 750-P5-G5-S5-HI-A20-R-E Relay Module ensures high performance and reliability, backed by the trusted brand of General Electric.
