Voltage Range:50-300 VDC / 40-265 VAC

Digital/Switch Inputs:6 optically isolated

Control Power:nominal: 20 VA; maximum: 65 VA

Dimensions:approx. 11.5 in H x 5.5 in W x 8.5 in L

Phase Current Inputs:1 A and 5 A secondary

Ambient Humidity:Maximum up to 95% non-condensing

Maximum Altitude:2000 m (max)

    The GE 369-HI-0-M-0-E-0 motor management relay is designed to provide comprehensive protection and monitoring for industrial motors.

     It features an optional metering package, allowing users to monitor motor performance and troubleshoot issues efficiently.

     With its waveform capture and event reporting capabilities, this relay enables operators to identify and address potential issues before they become critical.

     The compact design and robust build quality make it ideal for a wide range of industrial applications.

     Additionally, the relay supports various digital and switch inputs, providing flexible connectivity options for integration into existing systems.

     By improving the protective capabilities of the relay, users can adjust motor inrush current, cooling rates, and acceleration time to ensure optimal motor performance.
