Fisher DVC2000
Product Name
FIELDVUE DVC2000 Digital Valve Controller
Product Introduction
The Fisher DVC2000 is a compact digital valve controller that receives a 4–20 mA input signal and converts it into a pneumatic output for valve actuators. It is used for throttling and on/off control of industrial control valves.
Detailed content
Technical Specifications
Input Signal: 4–20 mA DC
Communication: HART
Output: Pneumatic for single-acting actuators
Supply Medium: Clean, dry air or non-corrosive gas
Maximum Inlet Pressure: 7 bar / 100 psig
Maximum Outlet Pressure: 7 bar / 101 psig
Operating Temperature: -40 °C to +80 °C
Housing Material: Aluminum alloy
Weight: Approximately 1.5–2.5 kg depending on configuration
Certifications: CSA, FM, ATEX, IECEx, UL, PED, INMETRO, NEPSI, others
Functional Features
Linkage-less magnetic position feedback
Local LCD and pushbutton interface
Automatic tuning
Continuous self-diagnostics
Integrated valve position transmitter
Optional limit switch functionality
Application Scenarios
Oil and gas
Chemical processing
Refining
Power generation
Water and wastewater
Pharmaceutical and food plants
Working Principle
The controller measures valve stem position with a non-contact magnetic sensor, compares it with the 4–20 mA setpoint, and modulates pneumatic pressure to the actuator until the valve reaches the commanded position.
Installation Requirements
Mount directly to actuator yoke using three-point interface
Ensure supply air is clean and dry
Position vent correctly for weatherproof operation
Verify NAMUR or actuator compatibility
Usage Notes
Terminal voltage must support analog and HART operation
Do not use contaminated or wet instrument air
Check alert records if fault symbol appears
Confirm area classification and certification before installation
