Emerson 5X00226G04 Controller Module
1. Technical Specifications
• Processor: Quad-core 1.6 GHz ARM-based CPU
• Memory: 64 MB non-volatile flash
• I/O Capacity: 512 points
• Scan Time: 5 ms typical
• Power Supply: 18–32 VDC
• Operating Temperature: −40 °C to +85 °C
• Humidity: 5 %–95 % RH non-condensing
• Certifications: IEC 61131-2, SIL3
• MTBF: 650,000 hours
Detailed content
2. Functional Highlights
• Triple Modular Redundancy (TMR): automatic “bumpless” failover between redundant controllers
• Multi-Protocol Ethernet: dual Gigabit Ethernet ports supporting Modbus TCP, Ethernet/IP, OPC UA, Profinet (via gateway)
• Advanced Diagnostics: self-test, real-time health monitoring, fault isolation, hot-swap capability
• Security: Achilles Level 1 certified, encrypted data exchange, role-based access
• Remote Firmware: upgrade via Emerson AMS Suite
• Triple Modular Redundancy (TMR): automatic “bumpless” failover between redundant controllers
• Multi-Protocol Ethernet: dual Gigabit Ethernet ports supporting Modbus TCP, Ethernet/IP, OPC UA, Profinet (via gateway)
• Advanced Diagnostics: self-test, real-time health monitoring, fault isolation, hot-swap capability
• Security: Achilles Level 1 certified, encrypted data exchange, role-based access
• Remote Firmware: upgrade via Emerson AMS Suite
3. Application Scenarios
• Power Generation: turbine control, renewable-energy integration
• Oil & Gas: refinery furnace control, offshore platform ESD systems
• Chemical & Metallurgy: process temperature, pressure and flow control
• Water & Wastewater: treatment plant automation, pump station SCADA
• Paper & Pulp: production line automation
• Power Generation: turbine control, renewable-energy integration
• Oil & Gas: refinery furnace control, offshore platform ESD systems
• Chemical & Metallurgy: process temperature, pressure and flow control
• Water & Wastewater: treatment plant automation, pump station SCADA
• Paper & Pulp: production line automation
