Berkeley Process Control ASM81-B-0B-00-NB10
Product Name
Industrial control/motion module; public distributor documentation shows conflicting variants for the ASM81 family.
Overview
ASM81-B-0B-00-NB10 is listed in industrial surplus documentation as a Berkeley Process Control automation module. Available public sources describe more than one configuration under similar ASM81 naming, so exact function must be confirmed from the nameplate, firmware label and system BOM.
Detailed content
Technical Specifications – Variant A
- Manufacturer: Berkeley Process Control
- Input voltage: 120 VAC
- Output voltage: 0–10 VDC
- Current rating: 6.6 A
- Communication: RS485
- Operating temperature: -10°C to +50°C
Technical Specifications – Variant B
- Type: multi-axis motion control module
- Control modes: position, velocity, torque closed-loop
- Feedback: encoder/high-resolution feedback
- Operating temperature: -20°C to +70°C
- Mounting: industrial rack plugin
- Features: interpolation, fault diagnosis, host communication
Technical Specifications – Variant C
- Supply: 24 VDC in some distributor listings
- I/O: 16DI/16DO in listed configuration
- Communication: RS485, Ethernet, Modbus, EtherCAT in listed configuration
- Response time: ≤1 ms
- Protection: IP20
- Mounting: DIN rail in listed configuration
- Weight: approximately 0.5 kg
Functional Features
Depending on variant: analog output control, RS485 parameter setting, multi-axis servo/stepper interpolation, encoder closed-loop correction, digital I/O scanning, industrial bus communication, fault/alarm monitoring.
Application Scenarios
Process analog control, servo positioning platforms, semiconductor handling, packaging machines, machine-tool axes, distributed I/O panels.
Material Composition
Industrial metal/plastic housing in rack variants, high-density PCB, gold-plated or industrial-grade connectors in listed motion variants, DIN-mounted terminal and RJ45 interfaces in listed I/O variants.
Structural Characteristics
Rack plugin card or DIN rail module depending on variant; front status LEDs; rear bus/encoder/motor connectors or terminal blocks; locking mechanism for rack versions.
Working Principle
For analog/output variants, incoming AC or bus power is converted to controlled DC/analog output and communicated through RS485 or host interface. For motion variants, the module receives trajectory commands, performs interpolation and PID/closed-loop calculation, drives servo/stepper amplifiers, and corrects position using encoder feedback. For I/O variants, it scans digital channels and exchanges data over industrial Ethernet/RS485.
Installation Requirements
Confirm variant before installation. For 120 VAC/analog variant, supply rated AC, isolate control wiring and use shielded analog cable. For motion variant, seat in designated rack slot, connect motor power, encoder and safety limit circuits separately. For 24 VDC I/O variant, mount on DIN rail, use rated power supply and segregated signal/cable trays.
Usage Precautions
Do not mix ASM81 variant parameters. Verify nameplate voltage, output rating and firmware. Use shielded encoder/communication cables with proper grounding. Avoid hot swapping rack modules under power. Perform homing/limit verification before motion commissioning.
