Bently Nevada 3500/72M 135489-01 Machine Train Monitor Module
Technical Specifications:
-
Channels: 8 dynamic, 2 speed, 2 analog 4-20 mA
-
Frequency Range: 0.1 Hz – 20 kHz
-
Measurement Types: Overall, spectrum, orbit, trend, phase
-
Signal Processing: Real-time FFT, envelope, cepstrum
-
Alarms: Multivariable, train logic, load-based
-
Isolation: 500 V
-
Power: 10 W
-
Operating Temperature: 0 °C to +65 °C
Detailed content
Functional Features:
-
Train logic correlates alarms across coupled machines
-
Load-based alarming uses 4-20 mA process input
-
Automatic bump-test for natural frequency identification
-
SIL 2 suitable for machine train protection
Application Scenarios:
-
Motor-gear-centrifugal pump trains in LNG plants
-
Steam turbine-driven boiler feed pumps
-
Integrally geared air compressors
-
Multi-stage ethylene refrigeration trains
