Bently Nevada 170180-01-00 FieldMonitor External Transducer I/O Module
Technical Specifications:
-
Channels: 2
-
Input Type: –24 VDC Proximitor supply, 0-10 V return
-
Transducer Compatibility: 5 mm, 8 mm and 11 mm Bently probes
-
Frequency Response: 1 Hz – 10 kHz
-
Output to Monitor: 0-10 V differential
-
Supply Voltage: 24 VDC ±20 %
-
Current Consumption: 20 mA excluding probe
-
Operating Temperature: –40 °C to +85 °C
-
Storage Temperature: –40 °C to +105 °C
-
Vibration: 10 g peak, 10-2,000 Hz
-
Shock: 50 g, 11 ms half-sine
-
Dimensions: 31 × 190 × 128 mm
-
Weight: 272 g
Detailed content
Functional Features:
-
Plug-in spring terminals for quick wiring
-
Integral –24 V supply eliminates separate driver
-
Continuous transducer OK and short detection
-
Epoxy-sealed electronics for wash-down areas
Application Scenarios:
-
Small gas-turbine generator sets
-
Integrally geared compressor thrust position
-
Boiler feed-pump coupling misalignment monitoring
-
Retrofit of obsolete 7200 series drivers
