Technical Specifications

1. Model: Bently 3500/05-01-00-00-00
2. Type: Tachometer Module
3. Channels: The module is designed to support a single channel for tachometer input.
4. Measurement Range: Measures rotational speed or shaft speed. The specific range varies depending on the application and sensor type used. Detailed measurement ranges are provided in the datasheet.
5. Output Signal: Provides output signals that are typically processed for display or integration into monitoring systems. Output formats can include digital signals or analog signals, depending on configuration.
6. Frequency Response: Designed to measure rotational speeds accurately within a specified frequency range. Detailed frequency response characteristics are available in the datasheet.
7. Operating Temperature Range: Usually operates effectively within a temperature range of -40°C to +70°C (-40°F to +158°F), suitable for a wide range of industrial environments.
8. Protection Rating: Typically meets high protection standards, often with an IP20 rating, which indicates protection against dust and accidental contact.

Features

1. High Precision Speed Measurement: Provides accurate measurement of rotational speed, essential for monitoring and controlling machinery performance.
2. Integration with 3500 Series: Seamlessly integrates with other modules in the Bently 3500 Series, allowing for a comprehensive machinery monitoring and protection system.
3. Real-Time Monitoring: Offers real-time processing of rotational speed data, enabling immediate insights into machinery performance.
4. Flexible Output Options: Can be configured to provide various types of outputs compatible with different monitoring and control systems.
5. Diagnostic Capabilities: Capable of supporting diagnostic functions to help identify issues with machinery speed and performance.

Application Scenarios

1. Machinery Condition Monitoring: Essential for monitoring the rotational speed of critical machinery such as turbines, compressors, and motors. Helps in ensuring that equipment operates within designed speed parameters.
2. Predictive Maintenance: Supports predictive maintenance strategies by providing accurate speed data, which can help in forecasting potential issues related to speed fluctuations or anomalies.
3. Industrial Automation: Used in automated systems to monitor and control rotational speed, contributing to optimized machinery performance and reduced downtime.
4. Power Generation and Oil & Gas: Applied in industries such as power generation and oil & gas, where precise speed measurement of critical equipment is crucial for maintaining operational efficiency and safety.

Usage Considerations

1. Installation: Proper installation is critical to ensure accurate speed measurements. The module should be correctly mounted and connected to the appropriate tachometer sensor.
2. Calibration: Regular calibration may be required to maintain the accuracy of speed measurements and ensure reliable operation.
3. System Integration: Ensure compatibility with other 3500 Series modules and monitoring systems to achieve a cohesive and effective monitoring setup.
