Bently 3500/65 Channel Temperature Monitor – RTD & thermocouple inputs, high density
Technical Specifications:
-
Channels: 16
-
Input Types: RTD Pt100, Pt1000, thermocouple J, K, E, T, N, R, S, B
-
Accuracy: ±0.5 °C for RTD, ±1 °C for TC
-
Resolution: 0.1 °C
-
Update Rate: 1 s per channel
-
Isolation: 500 V channel-to-channel
-
Outputs: 4-20 mA isolated per channel, 500 Ω max load
-
Alarms: Two level-plus-rate-of-change per channel
-
Power: 8 W
Detailed content
-
Operating Temperature: –30 °C to +65 °C
-
Dimensions: 241 × 24 × 242 mm
-
Weight: 0.91 kg
-
Agency Approvals: CE, UL, ATEX Zone 2, SIL 2 capable
Functional Features:
-
Automatic sensor break detection
-
Cold-junction compensation for thermocouples
-
Same hot-swap and interchangeability
Application Scenarios:
-
Motor stator winding hotspot mapping – 16 RTDs across 600 MW generator
-
Bearing pad temperature trending – triggers lift-oil pump when >110 °C
-
Gearbox oil temperature cascade control – 4-20 mA to DCS for cooler fan speed
