Technical Specifications

1. Model: Bently 3500/42
2. Type: 3-Channel Proximitor Module
3. Channels: Supports three channels, allowing for simultaneous measurement of displacement or proximity from three separate sensors.
4. Measurement Range: Designed to measure displacement in the micrometer range. The specific measurement ranges depend on the sensors used and are detailed in the datasheet.
5. Output Signal: Provides various output options including analog signals (e.g., 4-20 mA) for displacement and relay outputs for alarm conditions.
6. Frequency Response: Capable of measuring a wide range of frequencies, suitable for various industrial applications. Detailed frequency response characteristics are provided in the datasheet.
7. Operating Temperature Range: Typically operates within a temperature range of -40°C to +70°C (-40°F to +158°F), suitable for diverse industrial environments.
8. Protection Rating: Often features an IP20 rating, which provides protection against dust and accidental contact. Specific protection details can be confirmed in the datasheet.

Features

1. Multi-Channel Capability: Allows for simultaneous monitoring of three proximity or displacement sensors, providing comprehensive data on machinery movement and alignment.
2. High Precision Measurement: Delivers accurate measurement of displacement, essential for detecting misalignment, imbalance, and other issues that could affect machinery performance.
3. Real-Time Data Processing: Processes data in real-time, allowing for immediate insights into machinery condition and prompt responses to changes.
4. Alarm and Diagnostic Features: Includes alarms and diagnostic capabilities to alert operators of potential issues and support early detection of machinery problems.
5. Integration with 3500 Series: Seamlessly integrates with other modules in the Bently 3500 Series, offering a unified machinery protection and monitoring solution.

Application Scenarios

1. Machinery Alignment and Balancing: Ideal for monitoring the alignment and balancing of rotating machinery such as turbines, compressors, and generators. Helps ensure proper operation and prevent damage due to misalignment.
2. Condition Monitoring: Used for condition monitoring of critical equipment, providing data that is crucial for maintaining optimal performance and extending equipment life.
3. Predictive Maintenance: Supports predictive maintenance strategies by offering detailed displacement data that can help forecast potential issues and plan maintenance activities.
4. Industrial Automation: Applied in automated systems to monitor machinery alignment and movement, contributing to smooth and efficient operation.

Usage Considerations

1. Installation: Proper installation is crucial for accurate measurement. Ensure that the module is correctly mounted and connected to the proximity sensors.
2. Calibration: Regular calibration may be required to maintain measurement accuracy and reliable operation.
3. System Integration: Ensure compatibility with other Bently 3500 Series modules and monitoring systems to achieve a comprehensive and integrated monitoring solution.
