Bently 3500/32 Channel Relay Module
Technical Specifications:
-
Channels: 4 independent Form-C relays
-
Contact Rating: 5 A @ 250 VAC, 5 A @ 30 VDC
-
Operate Time: <10 ms
-
Isolation: 1,500 V coil-to-contact
-
Power: 24 VDC from rack, 5 W
-
Operating Temperature: –30 °C to +65 °C
-
Approvals: CE, UL, SIL 2 capable
Detailed content
Functional Features:
-
LED per relay indicating coil energized
-
Relay test push-button on front panel
-
Fail-safe mode selection
-
Hot-swappable replacement
Application Scenarios:
-
Gas-turbine fuel-trip solenoid actuation
-
Compressor suction valve emergency closure
