Bently 3500/15 127610-01
Product Introduction:
A DC-input variant of the 3500/15 supply that accepts 24 VDC plant batteries and converts them to regulated +24 VDC, ±12 VDC and +5 VDC rails required by the 3500 back-plane. It enables battery-backed or solar-powered installations.
A DC-input variant of the 3500/15 supply that accepts 24 VDC plant batteries and converts them to regulated +24 VDC, ±12 VDC and +5 VDC rails required by the 3500 back-plane. It enables battery-backed or solar-powered installations.
Technical Specifications:
-
Input Voltage: 20-30 VDC, reverse-polarity protected
-
Output: +24 VDC @ 5 A, +5 VDC @ 10 A, ±12 VDC @ 1 A
-
Power: 120 W continuous
-
Efficiency: 87 % @ 24 VDC in
-
Ripple: <50 mV pp on all rails
-
Hold-up Time: 10 ms @ full load
-
Protection: Under-voltage lockout, over-current, short-circuit, thermal
Detailed content
-
Operating Temperature: –40 °C to +70 °C
-
Storage Temperature: –55 °C to +85 °C
-
Dimensions: 120.7 × 50.8 × 251.5 mm
-
Weight: 1.39 kg
-
LEDs: Green “IN OK”, green “OUT OK”, red “Fault”
-
Approvals: CE, UL, cUL, ATEX, IECEx
Functional Features:
-
Hot-swap identical to AC versions
-
Load-sharing with redundant partner
-
Conformal-coated boards for condensation environments
-
No fan – convection cooled
Application Scenarios:
-
24 VDC battery-backed turbine protection panels
-
Solar-powered remote pump stations
-
Offshore platforms with DC distribution
-
Nuclear plant 125 VDC battery rooms
