Bently 330780-90-00
Product Introduction:
The 11 mm Proximitor driver converts the high-frequency eddy-current signal from the probe into a calibrated DC voltage proportional to gap. The 9 m system length suits large machines or remote instrument rooms.
The 11 mm Proximitor driver converts the high-frequency eddy-current signal from the probe into a calibrated DC voltage proportional to gap. The 9 m system length suits large machines or remote instrument rooms.
Technical Specifications:
-
System Length: 9.0 m (probe + extension)
-
Supply Voltage: –24 VDC ±1 V, 12 mA typical
-
Output: –2 to –18 VDC linear over 4 mm range
-
Sensitivity: 3.94 V/mm (100 mV/mil)
-
Linearity: ±0.5 % full scale
-
Frequency Response: 0 – 8 kHz
Detailed content
-
Load: 10 kΩ minimum
-
Mounting: 4-hole panel footprint
-
Terminations: SpringLoc screw-less clamps
-
Operating Temperature: 0 °C to +65 °C
-
Isolation: 500 V channel-to-ground
-
Dimensions: 79 × 25 × 93 mm
-
Weight: 0.35 kg
Functional Features:
-
LED “OK” indicator for sensor loop verification
-
Hot-swappable when supply is maintained
-
Fully interchangeable with any 3300 XL 11 mm component
-
RFI/EMI immunity meets CE mark without metallic conduit
Application Scenarios:
-
Large cooling-tower fan gearboxes
-
Remote pipeline compressor stations
-
Gas-storage centrifugal compressors
