Technical Specifications:​

Processor: Intel IXP420 XScale, 266 MHz

Flash memory: 32 MB internal

Main memory: 128 MB RAM internal

Operating system: Microsoft Windows CE

Control software: TwinCAT 2 CE PLC runtime

Ethernet: 2 x RJ45 10/100 Mbit/s with internal switch

Terminal bus: K-Bus for Beckhoff Bus Terminals

Non-volatile memory: 128 KB NOVRAM

I/O DPRAM: 4 KB

I/O terminal supply: 2 A from K-Bus power stage

Power supply: 24 V DC, -15% to +20%

Dielectric strength: 500 V rms between supply and internal electronics

Maximum power loss: 6 W

Dimensions: 59 mm x 100 mm x 91 mm

Weight: approximately 250 g without heat sink, 375 g with DVI/USB heat sink option

Operating temperature: 0 °C to +55 °C

Storage temperature: -25 °C to +85 °C

Relative humidity: 95% non-condensing

Vibration/shock: EN 60068-2-6 and EN 60068-2-27/29

EMC: EN 61000-6-2 and EN 61000-6-4

Protection class: IP20

Approvals: CE, UL

Functional Features:​

Fanless embedded controller for cabinet installation

Internal Ethernet switch for line topology without external switches

K-Bus connection for digital, analog, communication and specialty terminals

NOVRAM retention for recipes, counters and process setpoints

TwinCAT IEC 61131-3 programming with online diagnostics

Performance Parameters:​

266 MHz XScale CPU for PLC logic, data handling and small motion coordination

32 MB flash for OS image and application project

128 MB RAM for runtime and process data

4 KB I/O DPRAM buffer between CPU and K-Bus terminals

2 A K-Bus terminal power for connected I/O slices

Material Composition:​

Housing: industrial molded plastic embedded PC case

Heat sink where required: aluminum passive cooling element

PCB: multilayer FR4 industrial board

K-Bus and Ethernet connectors: insulated housings with metal contacts

Structural Characteristics:​

Compact DIN-rail mountable CX CPU module

Front diagnostic LEDs for power, LAN, K-Bus and flash access

RJ45 Ethernet ports on the module front or system face

PC/104 or internal system bus stacking according to CX9000 configuration

No DVI/USB in the 1001 configuration; visualization is handled via Ethernet HMI

Working Principle:​

The controller boots Windows CE and TwinCAT from internal flash, loads the PLC project into RAM, scans K-Bus terminals through the I/O DPRAM, executes control logic, writes outputs and exchanges data over Ethernet. NOVRAM stores retained variables across power cycles, while the battery-backed clock provides timestamps.

Installation Requirements:​

Mount on a 35 mm DIN rail or in a CX system carrier inside an IP20 cabinet

Supply 24 V DC with appropriate fusing and proper earth grounding

Connect K-Bus Bus Terminals in the supported chain order

Reserve ventilation space and avoid enclosed non-ventilated compartments

Usage Precautions:​

Do not install DVI/USB peripherals not supported by the 1001 variant

Backup the TwinCAT project and flash image before firmware changes

Avoid electrostatic contact with K-Bus connectors and terminal rows

Keep ambient temperature within 0 °C to +55 °C and humidity below 95% condensing
