Model Type:Analog Input/Output

Module ID:PAAI216

Brand:Bachmann

Input Voltage Range:±10 V

Output Voltage Range:±10 V

Input Current:0 to 20 mA

Output Current:0 to 20 mA

Digital Resolution:14-bit

Max Input Current:35 mA

Max Output Current:35 mA

Operating Temperature:-30°C to +60°C

Weight:0.24 kg

Dimensions:148 mm x 112 mm x 49 mm

Power Supply:18 to 34 VDC

Current Consumption:Typically 70 mA @ 24 VDC

Communication Interface:RS-232/422/485

Baud Rate:Up to 1.5 Mbps

FIFO Buffer Size:128 bytes

Isolation:Single

Filtering:50 μs

Interrupt Channel:1

Connectivity:6-wire system

    The Bachmann PAAI216 Analog Input/Output Modules are engineered for seamless integration into complex industrial automation systems, ensuring precise data acquisition and control.

    Featuring an ultra-wide ±10 V input voltage range, these modules are capable of handling a broad spectrum of environmental conditions, making them ideal for demanding applications.

    With a digital resolution of 14 bits, the PAAI216 delivers exceptional accuracy and reliability, crucial for maintaining high performance in critical industrial processes.

    Equipped with robust isolation technology, these modules safeguard against electrical interference, guaranteeing stable operation in harsh environments.

    Compact yet powerful, the PAAI216’s design is optimized for space-saving installation without compromising on functionality. It supports both analog inputs and outputs, facilitating versatile use in various control scenarios.

    Designed with advanced filtering capabilities and equipped with an interrupt channel, this module enhances system responsiveness and efficiency, making it an indispensable component in today’s sophisticated automation setups.
