Technical Specifications​

Measuring Range​

1 mm typical; final range depends on probe diameter, conditioner and calibration target.

Linearity​

±0.05 percent of full scale.

Resolution​

0.01 µm, equal to 10 nm.

Frequency Bandwidth​

0 to 10 kHz typical.

Output Signal​

0 to 10 VDC or 4 to 20 mA, configurable by the connected conditioner.

Supply Voltage​

18 to 30 VDC.

Target Material​

Conductive metals including steel, aluminum, copper and brass.

Operating Temperature​

-10 to 80 °C at the sensor head.

Protection Rating​

IP67 sensor head, IP65 connector.

Cable Length​

2 m standard, up to 10 m on request.

Connector​

M12 × 1 four-pin or M8 according to sub-variant.

Certification​

CE according to the supplied declaration.

Functional Features​

Non-Contact Sensing​

Eliminates mechanical wear, friction and loading on the measured surface.

High Resolution Displacement​

Detects submicron position change and small runout values.

Vibration Measurement​

Captures dynamic motion within the 10 kHz bandwidth.

Temperature-Stabilized Output​

Maintains calibrated performance when used with the matched conditioner and target material.

Application Scenarios​

Rotating Machinery​

Turbine and compressor shaft displacement, axial position and radial vibration monitoring.

Machine Tools​

Spindle runout, thermal growth and tool gap measurement.

Semiconductor Equipment​

Precision stage vibration analysis and non-contact gap control.

Laboratory Metrology​

Small displacement calibration and dynamic motion verification.

Performance Parameters​

Static Accuracy​

Linearity remains within ±0.05 percent of full scale after factory calibration with the specified target.

Dynamic Response​

10 kHz bandwidth supports fast vibration signals and transient displacement events.

Output Stability​

0 to 10 V or 4 to 20 mA output remains stable when supply voltage, shielding and target material match the calibration data.

Structural Features​

Probe Head​

Cylindrical stainless steel housing; diameter and thread vary by range variant.

Cable Assembly​

Potted sensor cable with shielded signal conductors and sealed transition to connector.

Mounting Format​

Threaded body for perpendicular installation into machine brackets, fixtures or probe holders.

Material Composition​

Housing​

316L stainless steel for corrosion resistance and mechanical durability.

Coil Assembly​

Copper sensing coil encapsulated in high-temperature potting compound.

Cable Jacket​

Shielded industrial cable with oil-resistant and coolant-resistant outer sheath according to variant.

Connector Contacts​

Nickel or gold-plated contacts according to M12 or M8 sub-variant.

Working Principle​

The conditioner sends high-frequency current to the probe coil. When the coil faces a conductive target, eddy currents form in the target and change the coil impedance. The conditioner measures impedance variation caused by distance change, converts it into a linear displacement value, applies target-material compensation and outputs 0 to 10 V or 4 to 20 mA.

Installation Requirements​

Mount the probe perpendicular to the measured surface. Set the initial air gap within the linear range, normally near the midpoint of the specified measuring range. Use a clean, flat, conductive target with surface area at least three times the probe diameter. Connect shielded cable to the matched ASM conditioner and ground the shield according to the conditioner manual. Keep the probe away from unrelated metal objects that can create side eddy-current effects.

Usage Precautions​

Do not use the probe on non-conductive materials such as plastic, wood or ceramic. Do not exceed 30 VDC supply. Do not strike, drop or wrap tape around the sensing face. Recalibrate after changing probe, extension cable, conditioner or target material. Keep the operating temperature within -10 to 80 °C at the head and within the conditioner’s rated ambient range.
