AMAT 0190-27952
Product Name
Industrial digital I/O control module for AMAT semiconductor systems.
Product Introduction
Applied Materials 0190-27952 is listed in public spare-part sources as a digital I/O control module with optically isolated inputs and configurable relay outputs. Some third-party listings also describe 0190-27952 under gas-delivery or electrochemical-sensor categories; the digital I/O description below reflects the most consistent industrial control listings.
Detailed content
Technical Specifications
- Manufacturer: Applied Materials
- Type: digital I/O control module
- Digital inputs: 16 optically isolated channels in selected listings
- Relay outputs: 8 channels, NO/NC configurable in selected listings
- Output rating: 2 A at 30 VDC / 250 VAC in selected listings
- Supply: 24 VDC ±10%; typical consumption around 12 W in selected listings
- Communication: RS-485, EtherCAT, SECS/GEM, TCP/IP; Ethernet port plus serial ports in selected listings
- Operating temperature: -40–85°C in selected listings
- Storage temperature: -40–85°C in selected listings
- Humidity: 10–90% RH non-condensing
- Protection: IP20
- Dimensions: around 250 × 150 × 30 mm in selected listings
- Weight: around 1.0 kg in selected listings
- Compliance: CE, RoHS, UL, SEMI S2/S8 in selected listings
Function Features
- Isolates and conditions field digital signals
- Drives solenoids, indicators, relays, and interlock devices
- Supports real-time status reporting to fab host systems
- Provides configurable I/O logic and multi-protocol communication
- Operates in electrically noisy cleanroom control environments
Application Scenarios
- AMAT Centura, Endura, and Producer-series I/O control
- Valve, pump, heater, and interlock signal management
- Wafer transfer, load port, and process-chamber auxiliary control
- Industrial automation panels requiring isolated digital I/O
Material Composition
- PCB: industrial multilayer board with optical isolation
- Relays: configurable electromechanical relay outputs
- Connectors: Ethernet, RS-485, and high-density I/O terminals
- Housing: protective module enclosure suitable for panel or rack mounting
Structural Characteristics
- DIN-rail or panel-mount format in selected listings
- LED indicators for input, output, power, and communication status
- Removable I/O terminals in supported variants
- Segmented isolation between field side and logic side
Working Principle
Field switches and sensors feed opto-isolated inputs. The logic section debounces, filters, and maps states to the controller through the selected communication protocol. Output channels energize relays based on control commands, providing isolated actuation for valves, alarms, and safety devices.
Installation Requirements
- Verify 24 VDC supply and grounding before connection
- Select input sink/source type according to field devices
- Install in low-dust, non-corrosive cabinet with adequate ventilation
- Confirm communication protocol, node address, and host configuration
Usage Notes
- Do not exceed rated relay voltage or current
- Test output logic with load disconnected before process use
- Avoid shared grounds between high-power actuators and signal circuits
- Inspect relay contact wear during preventive maintenance
