AMAT 0190-07970
Product Name
Interlock and safety monitoring module for semiconductor tools.
Product Introduction
Applied Materials 0190-07970 is listed in public spare-part sources as a chamber/interlock control module for Producer SE and related AMAT platforms. Some third-party industrial listings present it as a general AMAT interlock module; selected distributors also list MKS 0190-07970 interlock hardware with different electrical parameters, so confirmation against the tool BOM is required.
Detailed content
Technical Specifications
- Manufacturer: Applied Materials in AMAT listings; MKS Instruments in selected distributor listings
- AMAT variant function: chamber safety interlock, hardware state verification, low-voltage safety-signal monitoring
- Third-party AMAT industrial variant: 24 VDC ±10%, 16 opto-isolated digital inputs, 8 relay outputs, RS-485/EtherCAT/SECS-GEM, Ethernet, 0–50°C or extended listings up to 85°C, IP20, around 250 × 150 × 30 mm
- MKS distributor variant: 12–36 VDC, 8 Form C relays, RS-485 Modbus, IP65, -40–85°C, around 6.5 × 6.5 × 12.5 cm, 0.7 kg
- Compliance: SEMI S2/S8, CE, UL, RoHS in selected listings
Function Features
- Monitors chamber doors, vacuum state, gas delivery, RF enable, and emergency-stop circuits
- Provides real-time safety voting and relay control
- Supports FPGA/microcontroller logic with fast abnormal-signal response in third-party listings
- Integrates with SECS/GEM, EtherCAT, RS-485, or Modbus depending on variant
- Offers rear-mount cabinet installation in third-party industrial descriptions
Application Scenarios
- AMAT Producer SE, Centura, and Endura safety loops
- CVD, PVD, etch, and wafer-transfer interlock systems
- Vacuum chamber state verification and robot/manipulator safety monitoring
- Industrial cabinet safety control where compatible voltage and protocol match
Material Composition
- PCB: industrial-grade multilayer board with safety isolation
- Relays: electromechanical or solid-state outputs depending on variant
- Connectors: industrial Ethernet, RS-485, and high-density I/O contacts
- Enclosure: open card format for AMAT chassis variant; panel/IP65 housing in MKS distributor variant
Structural Characteristics
- Card-edge or chassis slot format for AMAT variant
- Panel-mounted module format for selected industrial/MKS variants
- LED status indicators for inputs, outputs, communication, and faults
- Configurable NO/NC relay contacts in supported variants
Working Principle
Safety inputs pass through isolation and logic evaluation. The module compares monitored states against permitted process conditions, then activates or deactivates relay outputs to permit or inhibit gas, vacuum, RF, and motion operations. Communication variants report status to the host and accept remote reset within defined safety rules.
Installation Requirements
- Confirm OEM label, platform compatibility, and voltage before mounting
- Install in clean, low-dust, non-corrosive control environment
- For AMAT chassis variant, use designated card-edge slot; for panel variant, use specified cutout and torque
- Verify grounding, shielding, and ESD handling
Usage Notes
- Do not modify safety jumper, relay logic, or firmware revision without OEM approval
- Test all interlock loops after replacement
- Do not mix AMAT, third-party industrial, and MKS parameter sets interchangeably
- Record part revision, serial, and configuration before returning tool to production
