AMAT 0140-78028 Cable Harness Assembly
Product Description: A high-performance, custom-configured cable harness assembly designed for signal and power transmission in semiconductor manufacturing equipment. It serves as a critical interconnect between control modules, sensor arrays, and power distribution units within AMAT’s advanced process chambers.
Technical Specifications:
- Conductor Material: High-purity oxygen-free copper (OFC) for minimal signal loss
- Insulation: Fluoropolymer (FEP/PFA) rated for 200°C continuous operation
Detailed content
- Shielding: Multi-layer braided copper + foil shielding for EMI/RFI suppression
- Voltage Rating: 600V AC/DC
- Temperature Range: -55°C to +200°C
- Connector Type: Industry-standard MIL-DTL-38999 series circular connectors
- Length: Custom-configurable (typical 1.5m to 5m)
- Compliance: RoHS, SEMI S2, CE
Functional Features:
- Low insertion loss and high signal integrity for precision control signals
- Exceptional resistance to chemical vapors and thermal stress in vacuum environments
- Secure locking connectors prevent accidental disconnection during operation
- Color-coded wiring for simplified installation and maintenance
- Flex-life rated for >10,000 flex cycles in dynamic installations
Application Scenarios:
- Interconnect for Endura PVD, Centura CVD, and Producer Etch systems
- Signal routing between chamber control boards and vacuum gauges
- Power distribution to RF match networks and gas panel modules
- Robotics and wafer handling subsystem connections
- Metrology and sensor interface in advanced process modules
