AMAT 0100-71309
Product Name
VME communication and multifunction I/O control module.
Product Introduction
Applied Materials 0100-71309 is an industrial control module for AMAT semiconductor systems. Public spare-part listings describe it as a VMEbus I/O unit with digital, analog, power, and communication functions for connecting sensors, valves, motors, and host controllers.
Detailed content
Technical Specifications
- Manufacturer: Applied Materials
- Bus: VME/VMEbus; third-party industrial listings also mention Ethernet, Profibus DP, Modbus TCP/IP
- Logic voltage: 5 VDC
- Auxiliary voltage: 24 VDC
- Analog/digital I/O: multiple channels depending on configuration
- Operating temperature: 0–55°C in VME listings, 0–50°C in some industrial-module listings
- Storage temperature: -20–70°C
- Humidity: 10–90% RH non-condensing
- Protection: IP20 for enclosed industrial variant
- Dimensions: approximately 175 × 100 × 50 mm in third-party industrial listings
- Weight: around 1.2 kg in third-party industrial listings
- Compliance: CE, UL, RoHS in third-party industrial listings
Function Features
- Acquires digital switch signals and drives control outputs
- Processes analog input/output for process variables
- Supports interrupt handling and DMA in VME descriptions
- Provides programmable I/O configuration
- Integrates with VME host controller and external communication networks
Application Scenarios
- AMAT CVD, etch, PVD, and general semiconductor control systems
- Sensor signal acquisition and valve/motor control
- Process recipe data exchange
- Industrial automation cabinets requiring VME or modular I/O
Material Composition
- Board: multilayer FR-4
- Housing/shielding: metal shielding in VME listings, industrial plastic/metal mix in third-party listings
- Connectors: industrial-grade high-density connectors
- Components: isolated digital circuits, analog conditioning devices, VME interface ICs
Structural Characteristics
- Standard VME card format with front panel status LEDs
- Rear high-density backplane connector
- Communication ports and diagnostic indicators on supported variants
- Rear-mount style described in third-party industrial listings
Working Principle
The module operates as a VME slave or intelligent I/O controller. It receives host read/write transactions, conditions field signals, converts analog values, executes logic or protocol handling, and returns status data to the main controller.
Installation Requirements
- Mount in standard VME rack or 19-inch industrial cabinet according to variant
- Ensure 5 V and 24 V rails are within specification before power-up
- Maintain clearance for airflow and avoid dust, moisture, corrosive gas
- Verify pinout, slot address, and firmware compatibility before operation
Usage Notes
- Do not hot-swap unless the specific OEM revision is qualified for hot insertion
- Perform periodic inspection of connectors and indicator status
- Clean with dry soft material; avoid solvent contact with labels and connectors
- Confirm communication protocol settings before connecting to host networks
